APC Smart-UPS 750VA
This Product is currently not in offering
On back-order, will ship once in-stock
General Information
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SUA750RM1U |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS |
| Product Name | Smart-UPS 750VA |
| Marketing Information | |
| Product Type | Line-interactive UPS |
Technical Information
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15P |
| Receptacle Detail | 4 x NEMA 5-15R |
| Number of Battery & Surge Outlets | 4 |
| Cord Length | 8 ft (2.44 m) |
Power Description
| Load Capacity (VA) | 750 VA |
| Input Voltage | 120 V |
| Output Voltage | 120 V AC |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 480 J |
Management
| Alarm |
|
Controls/Indicators
| Status Indicators | LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators |
Interfaces/Ports
| Serial Port | Yes |
| USB | Yes |
Battery Information
| Battery Characteristics | Maintenance-free |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 7.10 Minute |
| Backup/Run Time (Half Load) | 23.60 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 2 Hour |
Environmental Conditions
| Maximum Operating Temperature | 113°F (45°C) |
| Sound Emission (A-Weighted) | 45 dB(A) |
| Thermal Dissipation | 130 BTU/h |
Physical Characteristics
| Product Color | Black |
| Height | 1.73" (44 mm) |
| Width | 17.01" (432 mm) |
| Depth | 25.98" (660 mm) |
| Rack Height | 1U |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 48.10 lb (21817.79 g) |
Miscellaneous
| Package Contents | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Warranty
| Limited Warranty | 2 Year |
| Additional Warranty Information | 2 years repair or replace |
