Zebra VC70N0 Ultra-Rugged Vehicle-Mounted Mobile Computer

Part No. VC70N0-MA0U702G8WR

by Zebra Technologies Corporation

Zebra VC70N0 Ultra-Rugged Vehicle-Mounted Mobile Computer

1 GHz - 512 MB RAM - 2 GB Flash Memory - 10.4" LCD - XGA - 1024 x 768 - Wi-Fi - IEEE 802.11a/b/g/n - Serial - USB - Windows Embedded Compact 7

Part No. VC70N0-MA0U702G8WR

by Zebra Technologies Corporation

$4831.99
General Information
ManufacturerZebra Technologies Corporation
Manufacturer Part NumberVC70N0-MA0U702G8WR
Brand NameZebra
Product ModelVC70N0
Product NameVC70N0 Ultra-Rugged Vehicle-Mounted Mobile Computer
Marketing Information

The VC70N0 is the right-sized device for all your material-handling vehicles. Its compact design improves visibility and safety while still providing a large high-resolution display for all the information operators need to improve productivity and task accuracy, in almost any lighting condition. The powerful VC70N0 supports traditional Telnet to modern browser-based graphic-rich applications, covering receiving, put-away, replenishment, picking, packing and shipping. You get the flexibility to add the options needed to maximize efficiency - including corded or cordless bar code scanners, keyboards and a variety of voice capabilities.

Product TypeVehicle Mount Terminal
Technical Information
Connectivity TechnologyWireless
Processor & Chipset
Processor Speed1 GHz
Memory
Standard Memory512 MB
Flash Memory2 GB
Display & Graphics
Screen Size10.4"
Graphics ModesXGA
Display Screen TypeLCD
TouchscreenYes
Display Resolution1024 x 768
Network & Communication
Wireless LANYes
Wireless LAN StandardIEEE 802.11a/b/g/n
Interfaces/Ports
Network (RJ-45)Yes
SerialYes
USBYes
CANbusYes
Software
Operating SystemWindows Embedded Compact 7
Physical Characteristics
Width8.90" (226.06 mm)
Depth2.40" (60.96 mm)
Length11.50" (292.10 mm)
Miscellaneous
Certifications & Standards
  • IP 66
  • MIL -STD 810G; Method 514.6
  • MIL -STD 810G; Method 516.6
  • MIL -STD 810G
  • IEC 68-2-5

Electrical Safety:

  • UL /cUL /IE C/EN 60950-1 Indoor Use
  • UL /cUL /IE C/EN 60950-22 Outdoor Use

EMI /RFI:

  • FCC Part 15, Class B
  • ICES 003 Class B
  • EN55022
  • EN 301 489-1
  • EN 301 489-17

WLAN:

  • FCC Part 15.247, 15.407
  • RSS-210
  • EN 300 328
  • EN 301 893
  • AS/NZS 4268

Flammability:

  • IEC UL 94-VO
Environmentally FriendlyYes
Environmental Compliance
  • Restriction of Hazardous Substances (RoHS)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
COOCN
ConditionNo
Warranty
Limited Warranty1 Year
batteries (1)
connector cables (1)
microphones (1)

Part No. HMN1089B

Zebra Wired Microphone - Handheld

miscellaneous devices (1)

Part No. KT-DSCNT-VC70-05R

Zebra Desiccant Bag - 5

mounting kits (2)

Part No. KT-ACCMNT-VC70-R

Zebra Mounting Bracket for Vehicle Mount Terminal

Part No. KT-U-MOUNT-VC70-R

Zebra Vehicle Mount for Vehicle Mount Terminal

REPLACING VC5090 U-MOUNT

power cords (14)

Part No. 50-16000-257R

Zebra AC Line Cord - 1.8m

Part No. 50-16000-217R

Zebra AC Line Cord - 5.9 ft Cord Length

Part No. 50-16000-256R

Zebra Standard Power Cord - 5.9 ft Cord Length - CEE 7/7

Part No. 23844-00-00R

Zebra US 7.5' AC Line Cord - 7.5 ft (2.29 m) Cord Length - United States

PWRS1400148R/14000241R/NEW PWR SUPL

Part No. 50-16000-219R

Zebra AC Line Cord

Part No. 50-16000-221R

Zebra AC Line Cord - 5.9 ft Cord Length

Part No. 50-16000-218R

Zebra AC Line Cord - 5.9 ft Cord Length

Part No. 50-16000-678R

Zebra AC Line Cord

Part No. 50-16000-671R

Zebra AC Line Cord

power supplies (1)

Part No. PWRS-9-60VDC-01R

Zebra Proprietary Power Supply - External - 60 V DC Input - 12 V DC Output

10A EXT VC70 9-60VDC

screens & filters (1)
