ATEN 2-Port VGA Switch with Audio

Part No. VS0201

by ATEN Technology, Inc

ATEN 2-Port VGA Switch with Audio

1920 x 1440 - 2 x 11 x VGA Out

Part No. VS0201

by ATEN Technology, Inc

$89.99
General Information
ManufacturerATEN Technology, Inc
Manufacturer Part NumberVS0201
Brand NameATEN
Product Name2-Port VGA Switch with Audio
Marketing Information

The VS0201 2-Port VGA Switch with Audio allows you to connect two audio/video source computers to a single monitor or projector with full audio and quickly switch between the devices for use.

VS0201 built-in bi-directional RS-232 serial port for high-end system control, and advanced RS-232 control. The unit ´s bi-directional RS-232 serial port also allows serial devices, such as touchscreens and barcode scanners to be included in the installation. With the ability to use high-end serial control devices via RS-232 commands allows the VS0201 to be controlled by secondary systems with advanced functions such as; port switching, auto switching, front panel pushbutton lock, and Power on Detection. The VS0201 is perfect for the meeting room, media centers, class rooms, or any presentation environment requiring multiple audio/video sources to be accessed on a single display.

Packaged Quantity1
Product TypeAudio/Video Switchbox
Technical Information
Connectivity TechnologyCable
Number of Input Devices Supported2
Number of Displays Supported1
Video
Graphics Modes
  • VGA
  • SVGA
  • UXGA
  • WUXGA
Maximum Video Resolution1920 x 1440
Maximum Video Bandwidth300 MHz
Interfaces/Ports
VGA InYes
VGA OutYes
Serial PortYes
Audio Line InYes
Audio Line OutYes
Number of VGA Inputs2
Number of VGA Outputs1
Media & Performance
Maximum Operating Distance213.25 ft (65000 mm)
Power Description
Input Voltage5.3 V DC
Power Consumption0.55 W
Physical Characteristics
Height1.73" (44 mm)
Width3" (76.10 mm)
Depth5.12" (130 mm)
Weight (Approximate)450 g
Miscellaneous
Package Contents
  • 2-Port VGA Switch with Audio
  • 1x Power Adapter
  • 1x User Instructions
Environmentally FriendlyYes
Environmental Compliance
  • Restriction of Hazardous Substances (RoHS)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
ConditionNo
UPC672792003677
