Elo 2D Barcode Scanner

Part No. E926356

by Elo Touch Solutions, Inc

Elo 2D Barcode Scanner

Plug-in Card Connectivity - 498.69 ft (152000 mm) Scan Distance - 1D, 2D - CMOS - USB - Black

Part No. E926356

by Elo Touch Solutions, Inc

$270.99
General Information
ManufacturerElo Touch Solutions, Inc
Manufacturer Part NumberE926356
Brand NameElo
Product Name2D Barcode Scanner
Marketing Information

Improve self-service and price-checker applications when you couple the 2D Barcode scanner with an Elo touchscreen. Change the way your customers interact in-store by deploying a new generation of price-checkers that can run apps and websites, allowing companies to utilize the product for brand messaging and endless aisle applications while maintaining the main purpose as a price checking solution. When coupling the 2D barcode scanner with Elo's I-Series for Android and EloView®, content and device management can be done with ease. EloView is a ground breaking platform from Elo that allows you to deploy content for kiosk based applications to multiple locations remotely.

POS and kiosk management can be even easier with EloView. A revolutionary interactive platform, EloView is a secure management platform for remote content delivery and device management. Whether you need to push new content to a device or simply change the screen brightness, EloView has got you covered. EloView software provides device setup, remote management, alerts, attract loops, and the ability to securely upgrade the operating system, applications, and content.

Product TypeBarcode Scanner
Technical Information
Connectivity TechnologyPlug-in Card
Scanning Capability
  • 1D
  • 2D
Barcode Symbology Supported1D Linear:
  • Codabar
  • Code 11
  • Code 128
  • Code 2 of 5
  • Code 39
  • Code 93 and 93i
  • EAN/JAN-13
  • EAN/JAN 8
  • IATA Code 2 of 5
  • Interleaved 2 of 5
  • Matrix 2 of 5
  • MSI
  • GS1 Databar
  • UPC-A
  • UPC E
  • UPC-A/EAN-13 with Extended coupon Code
  • Coupon GS1 Code 32(PARAF)
  • EAN-UCC Emulation
  • GS1 Data bar
2D Stacked:
  • Codablock A
  • Codablock F
  • PDF417
  • MicroPDF417
2D Matrix:
  • Aztec Code
  • Data Matrix
  • MaxiCode
  • QR Code
  • Chinese Sensible(Han Xin) code
Postal Codes:
  • Australian Post
  • British Post
  • Canadian Post
  • China Post
  • Japanese Post
  • Korea Post
  • Netherlands Post
  • Planet Code
  • Postnet
Image Sensor TypeCMOS
Scanning Distance498.69 ft (152000 mm)
Field of View (Horizontal)38°
Field of View (Vertical)29°
Maximum Ambient Light100000 lux
Interfaces/Ports
Host InterfaceUSB
Physical Characteristics
Form FactorModular
Product ColorBlack
Weight (Approximate)0.96 oz (27.215542 g)
Miscellaneous
Country of OriginSwitzerland
COOCN
ConditionNo
