Zebra MC9300 Handheld Mobile Computer

Part No. MC930B-GSHDG4NA

by Zebra Technologies Corporation

Zebra MC9300 Handheld Mobile Computer

1D, 2D - SE4770Scan EngineSnapdragon 2.20 GHz - 4 GB RAM - 32 GB Flash - 4.3" WVGA Touchscreen - LED - 53 Keys - Alphanumeric Keyboard - Android 8.1 Oreo - Wireless LAN - Bluetooth - Rugged - Battery Included - IP67, IP65

Part No. MC930B-GSHDG4NA

by Zebra Technologies Corporation

$2567.99
General Information
ManufacturerZebra Technologies Corporation
Manufacturer Part NumberMC930BGSHDG4NA
Brand NameZebra
Product SeriesMC9000
Product ModelMC9300
Product NameMC9300 Handheld Mobile Computer
Marketing Information

THE ULTIMATE ANDROID™ ULTRA-RUGGED COMBINATION KEYPAD/TOUCH MOBILE COMPUTER

Every day, over three million workers use an MC9000 Series mobile computer to streamline processes in warehouses and manufacturing plants all over the world. But now you need to handle and ship more orders every day, faster than ever. Introducing the mobile computer that can get it done, the MC9300 - the next evolution of the world's best-selling and most trusted enterprise mobile computer. Your workers get the ultimate in simplicity with Android, an operating system your workers already know well, a larger advanced touch display and more. Handle all of your applications with the ultimate in processing power and memory. New data capture capabilities include optional front and back cameras, extraordinary scan ranges and superior direct part mark (DPM) capture. The new battery runs twice as long as the MC9200 on a single charge. It's the most rugged MC9000 Series ever created, ready to outlast virtually every device in its class in any environment - including the freezer. New Mobility DNA solutions make device, OS security and battery management easy, while delivering better-than-ever robust wireless connections. And since you can run your existing TE apps right out of the box, migrating to Android couldn't be easier.

Power a full shift and beyond with maximum battery power

The PowerPrecision+ battery delivers the most battery power in its class - nearly twice the battery run time of the MC9200, plus fast charging and a wealth of battery statistics to better manage your battery pool. And with PowerPrecision Console, a free PC-based Mobility DNA tool, it's easy to identify and discard aging batteries, before they impact workforce productivity and your operations.

Dependably superior WiFi connections

With 2x2 Multiple-User Multiple Input Multiple Output (MU-MIMO) technology and WorryFree WiFi, a free Mobility DNA tool, you get increased WiFi range and speed, near instant application response times, unmatched roaming, exceptional voice quality and network diagnostics that help keep your WiFi network up and running at peak performance.

A lifetime security guard for Android

With LifeGuardTMfor AndroidTM, you get the security updates you need to keep your Zebra Android devices secure every day they are in service - along with easy end-to-end control of the OS update process, plus support for future versions of Android.

THE ULTIMATE ANDROID PLATFOR

MMaximum processor power and memory

The ultra-powerful 8-core processor combines with up to eight times the RAM and 16 times the Flash memory of the MC9200 to deliver superior performance on all your voice and data apps.

THE ULTIMATE IN APPLICATION SUPPORT

Run your Terminal Emulation (TE) apps, right out of the box

Integrated support for your TE apps makes it easy to migrate from Windows to Android - no backend modification or user training required. And when you're ready to turn your 'green screen' TE apps into elegant touch-centric intuitive screens to boost productivity, Mobility DNA's All-touch TE makes it easy.

Larger touchscreen with advanced technology

The large multi-touch 4.3 in. WVGA display allows your workers to view more business data, while providing best-in-class indoor/outdoor readability and data input flexibility. Use a finger - even with a thick glove - or a stylus. And users can interact with the screen even if the display is wet.

Bluetooth Low Energy (BLE) 5.0 for twice the speed and four times the range

Bluetooth peripheral performance is improved, while power requirements are reduced, extending battery cycle tim

Product TypeHandheld Terminal
Technical Information
Connectivity TechnologyWireless
Scanning Capability
  • 1D
  • 2D
Scan Engine ModelSE4770
Image Sensor TypeImager
Scanner RangeStandard Range
Google Mobile Services (GMS)Yes
Sensor Type
  • Light Sensor
  • Motion Sensor
  • Accelerometer
  • Gyroscope
Features
  • Water Resistant
  • Gorilla Glass
  • Push-to-talk
  • VoIP
  • Non Incendive
Drop Specification
  • Standard: 10 ft. (3.1m) drops at room temperature per MIL-STD-810G, 8 ft. (2.4m) drops to concrete across temperature per MIL-STD-810G
  • Freezer: 7 ft. (2.1m) drops to concrete across temperature per MIL-STD-810G.
Processor & Chipset
Processor TypeSnapdragon
Processor Model660
Processor CoreOcta-core (8 Core)
Processor Speed2.20 GHz
Memory
Standard Memory4 GB
Flash Memory32 GB
Memory Card Supported
  • microSD
  • SDHC
  • SDXC
Display & Graphics
Screen Size4.3"
Screen ModeWVGA
Screen Resolution800 x 480
Display Screen TypeLED
Touchscreen Information
TouchscreenYes
Multi-touch ScreenYes
Keyboard/Keypad
Number of Keys53
Keyboard TypeAlphanumeric
Network & Communication
Wireless LANYes
Wireless LAN StandardIEEE 802.11a/b/g/n/ac/d/h/i/k/r/w
BluetoothYes
Bluetooth StandardBluetooth 5.0 BLE
Near Field Communication (NFC)Yes
Interfaces/Ports
USBYes
USB Type-CYes
Software
Operating SystemAndroid 8.1 Oreo
Power Description
Power SourceBattery
Battery Information
Battery Capacity7000 mAh
Battery ChemistryLithium Ion (Li-Ion)
Battery IncludedYes
Battery Voltage3.60 V
Removable BatteryYes
Environmental Conditions
Operating Temperature-4°F (-20°C) to 122°F (50°C)
Storage Temperature-40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing)5% to 95%
Physical Characteristics
Form FactorGun
RuggedYes
Height7.40" (187.96 mm)
Width3.50" (88.90 mm)
Length9.40" (238.76 mm)
Weight (With Battery)1.69 lb (765 g)
Miscellaneous
Package Contents
  • MC9300 Handheld Mobile Computer
  • Battery
Application/Usage
  • Logistics
  • Manufacturing
  • Retail
  • Cold Chain
  • Government
Ingress Protection (IP) Rating
  • IP67
  • IP65
Country of OriginChina
TAA CompliantYes
Environmentally FriendlyYes
Environmental Compliance
  • Restriction of Hazardous Substances (RoHS)
  • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
COOCN
ConditionNo
Warranty
Limited Warranty1 Year
Additional Warranty Information

Subject to the terms of Zebra's hardware warranty statement, the MC9300 is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment.
