CyberPower Indoor FTTx Battery Backup CBN50U48A-1

48 VDC 50 W 12 V / 20 Ah IEC320 C7 2-Prong Cord 3YR Warranty

Part No. CBN50U48A-1

by CyberPower Systems, Inc

$215.99

Specifications

General Information

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	CBN50U48A-1
Brand Name	CyberPower
Product Series	Indoor FTTx Telecom
Product Model	CBN50U48A-1
Product Name	Indoor FTTx Battery Backup CBN50U48A-1
Marketing Information	Designed for interior use, CBN50U48A-1 Indoor CyberShield™ FTTx System supplies continuous 48 VDC to local power network interface devices (NID), cable telephone modems, wireless base stations, fiber to the home (FTTH), optical network terminals (ONT), and integrated access devices. Features of the CBN50U48A-1 include high-function design, cold start functionality, audible alarm signals with silence options, microprocessor intelligent control, a telemetry interface, optional extendable runtime, user-replaceable batteries, and LED indicators. It also comes with a three-year warranty.
Product Type	Standby UPS

Technical Information

Plug/Connector Type	IEC 60320 C7
Protection Type	Surge Lightning
Cord Length	10 ft (3.05 m)
Application/Usage	Cable Telephone Cable Modem Wireless Base Station Fiber to the Home Integrated Access Device Indoor Network Device Optical Network Terminal (ONT) FTTx System Telecommunication
Features	Audible Alarm

Power Description

Load Capacity (Watt)	50 W
Input Voltage	120 V AC 230 V AC
Input Voltage Range	90 V AC - 264 V AC
Output Voltage	48 V DC
Input Frequency	47 Hz 70 Hz

Management

Alarm	Battery Mode

Controls/Indicators

Status Indicators	LED Indicators: AC Output Battery

Battery Information

Number of Batteries	1
Battery Characteristics	Sealed
Battery Chemistry	Lead Acid
Battery Size	12V
Battery Capacity	20000 mAh
Hot Swappable	Yes
Replaceable Battery	Yes

Environmental Conditions

Minimum Operating Temperature	32°F (0°C)
Maximum Operating Temperature	104°F (40°C)
Storage Temperature	5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation	10000 ft (3048000 mm)
Maximum Storage Elevation	50000 ft (15240000 mm)

Physical Characteristics

Height	11.81" (299.97 mm)
Width	11.02" (279.91 mm)
Depth	3.90" (99.06 mm)
Form Factor	Tower
Weight (Approximate)	17 lb (7711.07 g)

Miscellaneous

Additional Information	Battery Quantity : 1 Battery Size : 12 V / 20 Ah Battery Type : Sealed Lead-Acid Battery Hot Swappable : Yes Typical Recharge Time : > 24 Hours User Replaceable Battery : Yes Physical Dimensions - (WxHxD) (cm) : 27.99 x 30.0 x 9.91 (cm) Physical Dimensions - (WxHxD) (in) : 11.02 x 11.81 x 3.9 (in) Physical Dimensions - (WxHxD) (mm) : 280 x 300 x 99 (mm) Weight (kg) : 7.71 Weight (lb) : 17 Shipping Dimensions - (WxHxD) (cm) : 35.56 x 18.42 x 35.26 (cm) Shipping - Dimensions (WxHxD, in) : 14.0 x 7.25 x 13.88 (in) Shipping - Dimensions (WxHxD, mm) : 355.6 x 184.15 x 352.55 (mm) Shipping - Weight (kg) : 6.3 Shipping - Weight (lb) : 13.88 Cord Length : 10 ft (3.0 m) Input Frequency Range : 47 Hz - 70 Hz Input Power Cord : IEC320 C7 2-Prong Cord Input Voltage Range : 90 VAC - 264 VAC Efficiency : > 85% On Battery Voltage : 48 VDC Output Ground Reference : Floating Ground Rated Power Output : 50 W USB Charge Port : No Lightning / Surge Protection : Yes Lightning / Surge Protection : Yes Audible Alarms : Battery Mode Communication Interface : On Battery LED Indicators : AC, Output, Battery Auto-Charge : Yes Operating Elevation : 0 - 10000 ft (0 - 3048 m) Operating Relative Humidity : 0 - 95 % (non-condensing) Operating Temperature : 32 - 104 °F (0 - 40 °C) Storage Elevation : 0 - 50000 ft (0 - 15239 m) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Safety : UL62368\|FCC Part 15 Class B\|CISPR 22 Class B Product Warranty : 3 Year Limited Warranty
Certifications & Standards	Safety: UL62368 FCC Part 15 Class B CISPR 22 Class B
Country of Origin	Philippines
Condition	No
UPC	0649532931903

Warranty

Limited Warranty	3 Year
