2N Access Unit 2.0 RFID MultiFrequency

Part No. 02146-001

by Axis Communications

$885.99

On back-order, will ship once in-stock

  • All Locations: (0+)

2N Access Unit 2.0 RFID MultiFrequency

Nickel, Black Residential

Part No. 02146-001

by Axis Communications

$885.99

On back-order, will ship once in-stock

  • All Locations: (0+)

General Information
ManufacturerAxis Communications
Manufacturer Part Number02146-001
Brand Name2N
Product NameAccess Unit 2.0 RFID MultiFrequency
Marketing InformationDo you need a good-looking access reader for your project? All the residents of luxury residences will be delighted with the 2N Access Unit 2.0. Select modern access with a mobile phone or fingerprint. Do you prefer conventional methods? We also o er an RFID card reader or keypad. Cannot decide? Select a combination of several methods in one device. But don't look for controllers in our portfolio. They are already an integral part of every reader.
Product TypeCard Reader Access Device
Technical Information
Application/UsageResidential
Features
  • RFID Card Reader
  • Surface Mount
  • Wall Mountable
  • Robust
  • PoE
  • Tamper Switch
  • Easy Installation
  • Bluetooth
  • Flush Mount
Physical Characteristics
Product Material
  • Zinc
  • Glass
Color FamilyDual Color
Product Color
  • Nickel
  • Black
Weight (Approximate)798.3 g
Miscellaneous
Additional Information
  • Power supply: PoE and/or 12 V/1 A DC
  • PoE: 802.3af (Class 0-12.95 W)
  • LAN: 10/100BASE-TX with Auto-MDIX, RJ-45 modular jack
  • Recommended cabling: Cat-5e or better
  • Active switch output: 8 to 12 V DC/max 600 mA
  • Passive switch: NO/NC contacts, up to 30 V/1 A AC/DC
  • Tamper switch: native part of the 2N Access Unit 2.0
  • Audio: buzzer (97dBA)
  • Supported protocols: DHCP opt. 66, SMTP, TFTP, HTTP, HTTPS, Syslog
  • Frame: robust zinc cast frame with surface finish (nickel and black color)
  • Operating temperature: -40°F to +140°F
  • Storage temperature: -40°F to +158°F
  • Operating relative humidity: 10%-95% (non-condensing)
Supported frequencies:
  • 125 kHz variant
  • 13.56 MHz variant
  • 125 kHz and 13.56 MHz variant
125 kHz:
  • EM4100
  • EM4102
  • HID Prox
13.56 MHz:
  • ISO14443A, ISO14443B, NFC support
  • reads UID (CSN)
  • reads PACs ID (HID iClass cards with SIO object)
Inputs:
  • 2 inputs - in passive/active mode (-30 V to +30 V DC)
  • OFF = open or Uin> 1.5 V
  • ON = short-circuit or Uin< 1.5 V
Dimensions:

Wall (surface) mounting frame:
  • 1 module: 4.2 (W) x 5.11 (H) x 1.10 (D) inch
Flush mounting frame:
  • 1 module: 5.11 (W) x 6.02 (H) x 0.19 (D) inch
Flush mounting box (minimum hole):
  • 1 module: 4.25 (W) x 5.15 (H) x 1.77 (D) inch
Compatibility
  • Axis 2N Access Control Unit
  • Axis 2N HID Prox Proximity Card

Axis 2N Card Readers:

  • EM4100
  • EM4102
Certifications & Standards
  • IP54
  • IK08
ConditionNo
UPC8595159515120
