Fortinet FortiAP U231F Dual Band 802.11ax 2.91 Gbit/s Wireless Access Point - Indoor
This Product is currently not in offering
On back-order, will ship once in-stock
General Information
| Manufacturer | Fortinet, Inc |
| Manufacturer Part Number | FAP-U231F-S |
| Brand Name | Fortinet |
| Product Line | FortiAP |
| Product Model | U231F |
| Product Name | FortiAP U231F Wireless Access Point |
| Marketing Information | This enterprise class Wi-Fi 6 (802.11ax) indoor AP provides three radios as well as features such as OFDMA and dual 1 Gbps Ethernet ports for PoE diversity. The APs can be configured for dual 5 GHz band access while still providing coverage for devices on the 2.4 GHz band, or can be configured to offer dedicated scanning. The integrated BLE radio can be used for beacons and locationing applications. |
| Product Type | Wireless Access Point |
Technical Information
| Wireless LAN Standard | 802.11ax |
| Network Band | Dual Band |
| Frequency Band |
|
| Total Number of Antennas | 5 |
| Number of Internal Antennas | 5 |
| Indoor/Outdoor | Indoor |
| Wireless Transmission Speed | 2.91 Gbit/s |
| MIMO Technology | Yes |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard |
|
Interfaces/Ports
| Ethernet Technology | Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 2 |
| PoE (RJ-45) Port | Yes |
| PoE PD Port | Yes |
| USB | Yes |
| Management Port | Yes |
Power Description
| Power Consumption | 18.50 W |
Physical Characteristics
| Form Factor |
|
| Antenna Form Factor | Internal |
| Height | 2.05" (52 mm) |
| Width | 6.50" (165 mm) |
| Depth | 6.50" (165 mm) |
| Weight (Approximate) | 1.50 lb (680 g) |
Miscellaneous
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | Taiwan |
Warranty
| Limited Warranty | Lifetime |
