NEC Display 55" Ultra High Definition Professional Display with Built-In Intel PC

Part No. M551-PC5

by Sharp

This Product is currently not in offering

NEC Display 55" Ultra High Definition Professional Display with Built-In Intel PC

Part No. M551-PC5

by Sharp

This Product is currently not in offering

General Information
ManufacturerSharp
Manufacturer Part NumberM551-PC5
Brand NameNEC Display
Product SeriesM
Product ModelM551-PC5
Product Name55" Ultra High Definition Professional Display with Built-In Intel PC
Marketing Information

Create pixel-perfect imagery with the high-end panel quality of the fully professional NEC M Series large format displays. By focusing on customer needs while also offering professional reliability, the M series displays give customers a digital signage display lineup without all the costs. The M series can support both landscape and portrait orientations while also containing a Coffee Lake Intel Celeron Windows 10 IoT Enterprise PC through the SDM-VICW-IS seamlessly integrated into the SDM-L slot on the side of the display. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters - the message. Simple and targeted connectivity options allow customers to have the up-to-date options that they need while not having to overpay for excess and unused interfaces. The NEC M series boasts 500 cd/m² brightness which is ideal for a majority of digital signage applications in corporate, higher education, restaurant, retail and grocery store environments when the focus should be on the message, not the budget.

  • 4K UHD native resolution allows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
  • Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
  • Integrated Coffee Lake Intel Celeron, Windows 10 IoT PC with the SDM-VICW-IS included in the SDM-L Slot
  • Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C
  • 500 cd/m2 brightness and HDR compatibilty will capture the attention of audience in almost any situation
  • Integrated Media Player allows for audio, video or image playback via USB
  • Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
  • Integrated Ambient Light Sensor allows the display to autmatically adjust its luminance based on external brightness conditions
  • Energy Star 8.0 Certified Product
  • Full 3 year commercial warranty to allow for peace of mind and protection of your investment
  • NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations
Product TypeDigital Signage Display/Appliance
Technical Information
Bezel Width (Top)0.47" (11.94 mm)
Bezel Width (Bottom)0.61" (15.49 mm)
Bezel Width (Left)0.49" (12.45 mm)
Bezel Width (Right)0.49" (12.45 mm)
Processor & Chipset
Processor TypeCeleron
Display & Graphics
Viewable Screen Size55" (1397 mm)
Display Screen TypeLCD
High Dynamic Range (HDR)Yes
High Dynamic Range (HDR) TypeHDR10
Display Resolution3840 x 2160
Backlight TechnologyDirect LED
Video
Scan Format2160p
Brightness500 cd/m²
Network & Communication
EthernetYes
Interfaces/Ports
USBYes
HDMIYes
DisplayPortYes
SerialYes
Number of HDMI Inputs2
Number of DisplayPorts1
Software
Operating SystemWindows 10 IoT Enterprise
Power Description
Input Voltage
  • 120 V AC
  • 230 V AC
Physical Characteristics
VESA Mount Standard300 x 300
Mount Type
  • Wall Mountable
  • Table Mount
Height28.10" (713.74 mm)
Width48.80" (1239.52 mm)
Depth2.40" (60.96 mm)
Weight (Approximate)58.20 lb (26399.08 g)
Miscellaneous
Package Contents
  • 55" Ultra High Definition Professional Display with Built-In Intel PC
  • 3m Power cord
  • 2.0m HDMI cable
  • Wireless remote control
  • Batteries
  • Intel Celeron Coffee Lake Windows 10 IoT PC (SDM-VICW-IS - Integrated)
  • Setup Guide
Energy StarYes
Environmentally FriendlyYes
Energy Efficiency CertificationENERGY STAR 8.0
Country of OriginChina
Warranty
Limited Warranty5 Year
