Planar UltraRes URX75-ERO-T Digital Signage Display
75" (1905 mm) LCD - Touchscreen - High Dynamic Range (HDR) - 24 Hours/7 Days Operation - 3840 x 2160 - Direct LED - 630 cd/m² - 2160p - HDMI - USB - SerialEthernet
$14083.99
On back-order, will ship once in-stock
- All Locations: (0+)
General Information
| Manufacturer | Leyard |
| Manufacturer Part Number | 998317000 |
| Brand Name | Planar |
| Product Line | UltraRes |
| Product Model | URX75-ERO-T |
| Product Name | UltraRes URX75-ERO-T Digital Signage Display |
| Marketing Information | The Planar UltraRes™ X URX75-ERO-T is a TAA Compliant, 4K, HDR, professional 75" LCD touch display with on-board processing for viewing up to four content sources simultaneously. It offers an OPS slot for additional connectivity, and a redundant power supply. With the optional Planar® Profile™ Mounting System it can achieve ADA compliance. It also features Planar® ERO-LCD™ protection technology for use in high-traffic and public environments. It offers high brightness, superior color performance with exceptional 4K clarity and multi-point touch for applications ranging from interactive meeting spaces to high impact touch-based digital signage. |
| Product Type | Digital Signage Display |
Technical Information
| Bezel Width | 0.73" (18.60 mm) |
| Bezel Width (Bottom) | 1.35" (34.40 mm) |
| Bezel Width (Top) | 1.35" (34.40 mm) |
| Bezel Width (Left) | 1.38" (35 mm) |
| Bezel Width (Right) | 1.38" (35 mm) |
| Operation Hours | 24 Hours/7 Days |
Display & Graphics
| Number of Screens | 1 |
| Viewable Screen Size | 75" (1905 mm) |
| Display Screen Type | LCD |
| Touchscreen | Yes |
| Multi-touch Screen | Yes |
| Number of Simultaneous Touchpoints | 20 |
| Display Resolution | 3840 x 2160 |
| High Dynamic Range (HDR) | Yes |
| High Dynamic Range (HDR) Type | HDR10 |
| Pixel Pitch | 16.92 mil (0.43 mm) |
| Backlight Technology | Direct LED |
Video
| Scan Format | 2160p |
| Dynamic Contrast Ratio | 20,000:1 |
| Color Depth | 10-bit |
| Brightness | 630 cd/m² |
| Color Gamut | 88% NTSC |
Network & Communication
| Ethernet | Yes |
| Wireless LAN | No |
Interfaces/Ports
| USB | Yes |
| HDMI | Yes |
| DisplayPort | Yes |
| Serial | Yes |
| Number of DisplayPorts | 1 |
Power Description
| Input Voltage |
|
Physical Characteristics
| Mount Type | Wall Mountable |
| Height | 39.34" (999.30 mm) |
| Width | 67.77" (1721.30 mm) |
| Depth | 4.09" (103.90 mm) |
| Weight (Approximate) | 174.17 lb (79000 g) |
Miscellaneous
| Package Contents |
|
| Application/Usage | Meeting Room |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TAA Compliant | Yes |
| Condition | No |
