CyberPower CPS1615RMS Rackbar 16 - Outlet Surge Protector with 1800 J Surge Suppression

Part No. CPS1615RMS

by CyberPower Systems, Inc

$84.99

In Stock Availability

  • All Locations: (13+)
  • Calgary, AB (3+)
  • Mississauga, ON (10+)
  • Toronto, ON (12+)
  • Vancouver, BC (6+)

CyberPower CPS1615RMS Rackbar 16 - Outlet Surge Protector with 1800 J Surge Suppression

Clamping Voltage 600V, 6 ft Cord, NEMA 5-15P, Straight, 15 Amp, EMI/RFI Filtration, Black, 3YR Warranty

Part No. CPS1615RMS

by CyberPower Systems, Inc

$84.99

In Stock Availability

  • All Locations: (13+)
  • Calgary, AB (3+)
  • Mississauga, ON (10+)
  • Toronto, ON (12+)
  • Vancouver, BC (6+)

General Information
ManufacturerCyberPower Systems, Inc
Manufacturer Part NumberCPS1615RMS
Brand NameCyberPower
Product SeriesRackbar Surge
Product ModelCPS1615RMS
Product NameCPS1615RMS
Marketing Information

Engineered for the most demanding applications, the professional-grade Rackbar CPS1615RMS safeguards systems and networking equipment by absorbing spikes in energy caused by storms and electrical power surges. Designed for network environments, the CPS1615RMS also performs superbly for home office use, providing 1800 joules of protection, 15-Amp electrical capacity with circuit breaker, and 16 surge-protected outlets (6 front, 10 rear). Industrial-grade metal housing keeps this Rackbar performing flawlessly. The CPS1615RMS has a 1U racksize and can be mounted horizontally.

Features of the CPS1615RMS include an EMI/RFI noise filter, industrial-grade metal housing, AC power cord (6 ft.). The CPS1615RMS also comes with a three-year limited warranty.

Product TypeSurge Suppressor/Protector
Technical Information
Plug/Connector TypeNEMA 5-15P
Receptacles16 x NEMA 5-15R
FeaturesOverload Protection
Power Description
Input Voltage125 V AC
Output Voltage125 V AC
Maximum Surge Current90 kA
Surge Energy Rating1800 J
Circuit BreakerYes
Clamp Voltage600 V
Maximum Spike Voltage6 kV AC
Environmental Conditions
Minimum Operating Temperature32°F (0°C)
Maximum Operating Temperature95°F (35°C)
Minimum Storage Temperature5°F (-15°C)
Maximum Storage Temperature113°F (45°C)
Physical Characteristics
Color FamilyBlack
Product ColorBlack
Product MaterialMetal
Power Cord/Cable Length6 ft (1.83 m)
Form FactorRack-mountable
Rack Height1U
Height1.75" (44.45 mm)
Width19" (482.60 mm)
Depth4.60" (116.84 mm)
Weight (Approximate)4.26 lb (1932.30 g)
Miscellaneous
Application/UsageNetwork Device
Additional Information
  • Physical Dimensions - (WxHxD) (cm) : 48.26 x 4.45 x 11.68 (cm)
  • Physical Dimensions - (WxHxD) (in) : 19 x 1.75 x 4.6 (in)
  • Physical Dimensions - (WxHxD) (mm) : 483 x 44 x 117 (mm)
  • Weight (kg) : 1.93
  • Weight (lb) : 4.26
  • Shipping Dimensions - (WxHxD) (cm) : 54.86 x 5.49 x 17.48 (cm)
  • Shipping - Dimensions (WxHxD, in) : 21.6 x 2.16 x 6.88 (in)
  • Shipping - Dimensions (WxHxD, mm) : 548.64 x 54.86 x 174.75 (mm)
  • Shipping - Weight (kg) : 2.11
  • Shipping - Weight (lb) : 4.65
  • Circuit Breaker : 15 A
  • Cord Length : 6 ft (1.8 m)
  • Input Plug Type : NEMA 5-15P
  • Maximum Input Current : 15A
  • Nominal Input Voltage : 125 VAC
  • Plug Style : Straight
  • Switch : Lighted On/Off
  • Nominal Output Voltage : 125 VAC
  • Outlets - Front : 6
  • Outlets - Rear : 10
  • Outlets - Total : 16
  • Outlet Type COMPUTED : 16 - NEMA 5-15R
  • Overload Protection : 15A
  • USB Charge Port : No
  • Clamping Voltage : 600V (H-N, H-G, N-G)
  • EMI/RFI Filtration COMPUTED : 150 KHz
  • Maximum Surge Current : 90000 A
  • Maximum Surge Current H-G : 30000 A
  • Maximum Surge Current H-N : 30000 A
  • Maximum Surge Current N-G : 30000 A
  • Maximum Surge Voltage : 6000 V
  • Surge Suppression (Joules) : 1800 J
  • Clamping Voltage : 600V (H-N, H-G, N-G)
  • EMI/RFI Filtration COMPUTED : 150 KHz
  • Maximum Surge Current : 90000 A
  • Maximum Surge Current H-G : 30000 A
  • Maximum Surge Current H-N : 30000 A
  • Maximum Surge Current N-G : 30000 A
  • Maximum Surge Voltage : 6000 V
  • Surge Suppression (Joules) : 1800 J
  • Color : Black
  • Cord Retention Tray/Cord Organizers : Yes
  • Form Factors Supported : 1U Rackmount
  • Material of Construction : Metal
  • Rack Height : 1U
  • Operating Elevation : 0 - 9843 ft (0 - 3000 m)
  • Operating Relative Humidity : 0 - 95 % (non-condensing)
  • Operating Temperature : 32 - 95 °F (0 - 35 °C)
  • Storage Elevation : 0 - 49213 ft (0 - 14999 m)
  • Storage Temperature : 5 - 113 °F (-15 - 45 °C)
  • Environmental : RoHS Compliant
  • Safety : UL 1363, UL 1449
  • CEG Amount : $0
  • Connected Equipment Guarantee : No
  • Product Warranty : 3 Year Limited Warranty
    • Certifications & Standards
  • UL 1363
  • UL 1449
    • Environmental ComplianceRestriction of Hazardous Substances (RoHS)
    ConditionNo
    UPC0649532936632
    Warranty
    Limited Warranty3 Year
