Vertiv Geist rPDU MN05M1R0-10D203-2ST5A0H10-S 10-Outlets PDU

Part No. VP4N21A0

by Vertiv

$998.99

On back-order, will ship once in-stock

  • All Locations: (0+)

Vertiv Geist rPDU MN05M1R0-10D203-2ST5A0H10-S 10-Outlets PDU

Monitored - NEMA 5-20P - 10 x NEMA 5-20R - 120 V AC - Network (RJ-45) - 10 ft (3.05 m) Cord Length - 1U - Horizontal - Rack-mountable

Part No. VP4N21A0

by Vertiv

$998.99

On back-order, will ship once in-stock

  • All Locations: (0+)

General Information
ManufacturerVertiv
Manufacturer Part NumberVP4N21A0
Brand NameVertiv Geist
Product SeriesrPDU
Product ModelMN05M1R0-10D203-2ST5A0H10-S
Product NamerPDU MN05M1R0-10D203-2ST5A0H10-S 10-Outlets PDU
Marketing Information

Upgradeable Unit Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of input level power usage via remote network access. Includes environmental monitoring capabilities to obtain realtime environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs.

Benefits

  • Reliable power distribution with local and remote power monitoring options offer quick access to critical power usage information to evaluate energy usage trends and maximize uptime
  • Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime.
  • Fault-Tolerant Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a breakin the network chain occurs. Supports up to 40 rPDUs.
  • Every unit is 100% tested for reliability and functionality.
  • Daisy-chain up to 50 devices on a single IP address and reduce deployment time with self-configuration of downstream devices.
Product TypePDU
Technical Information
PDU TypeMonitored
Plug/Connector TypeNEMA 5-20P
Plug/Connector Detail1 x NEMA 5-20P
Receptacle TypeNEMA 5-20R
Receptacle Detail10 x NEMA 5-20R
Features
  • Touch Screen Display
  • LCD Display
Load Capacity (Watt)1.90 kW
Power Description
Input Voltage120 V AC
Input Voltage Range100 V AC - 120 V AC
Output Voltage120 V AC
Power Rating (Watt)1.90 kW
Input Current20 A
Input Frequency60 Hz
Management
Management
  • DHCP
  • HTTP
  • HTTPS
  • IPv4
  • IPv6
  • LDAP
  • NTP
  • RADIUS
  • RSTP
  • SSH
  • SMTP
  • SNMP (v1/v2c/v3)
  • Syslog
  • TACACS+
  • Modbus TCP
  • CSV datalog
  • JSON API
  • JSON datalog
Interfaces/Ports
Network (RJ-45)Yes
Physical Characteristics
Color FamilyBlack
Product ColorBlack Powder Coat
Mounting OrientationHorizontal
Mount TypeRack-mountable
Rack Height1U
Cord Length10 ft (3.05 m)
Height1.72" (43.69 mm)
Width17" (431.80 mm)
Depth8.50" (215.90 mm)
Environmental Conditions
Maximum Operating Temperature140°F (60°C)
Miscellaneous
Application/UsageIT Equipment
Certifications & Standards
  • UL
  • c-UL Listed 62368-1
  • FCC Part 15 Class A
Country of OriginUnited States
TAA CompliantYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
ConditionNo
Warranty
Limited Warranty5 Year
Additional Warranty Information

5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years
