Sharp NEC Display 55" Ultra High Definition Professional Display

Part No. M551-2

by Sharp

Sharp NEC Display 55" Ultra High Definition Professional Display

55" (1397 mm) LCD - Vertical Alignment (VA) - High Dynamic Range (HDR) - 24 Hours/7 Days Operation - 3840 x 2160 - 16:9 - 8 ms - Direct LED - 500 cd/m² - 2160p - HDMI - USB - SerialEthernet - Energy Star

Part No. M551-2

by Sharp

$2195.99
General Information
ManufacturerSharp
Manufacturer Part NumberM551-2
Brand NameSharp NEC Display
Product LineMultiSync
Product SeriesM
Product ModelM551-2
Product Name55" Ultra High Definition Professional Display
Marketing Information

Create pixel-perfect imagery with the high-end panel quality of the fully professional NEC M Series large format displays. By focusing on customer needs while also offering professional reliability, the M series displays give customers a digital signage display lineup without all the costs. The M series can support both landscape and portrait orientations while also allowing the modularity possibilities to customize their needs dependent on their application and use. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters - the message. Simple and targeted connectivity options allow customers to have the up-to-date options that they need while not having to overpay for excess and unused interfaces. The NEC M series boasts 500 cd/m² brightness which is ideal for a majority of digital signage applications in corporate, higher education, restaurant, retail and grocery store environments when the focus should be on the message, not the budget. Share your message, your way.

  • 4K UHDnative resolutionallows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
  • Landscape and Portrait orientationallows for flexibility of installation dependent on your needs
  • Accepts Intel® Smart Display Module Small or Largeallowing for sleek all-in-one intelligence and interoperability in a small form factor setting by accepting Intel processor-based products and other peripherals directly into the displays*
  • Raspberry Pi Compute Module 4allows for future proof expansion directly into the display
  • Bidirectional and Full External Controlallows for easy integration into control systems via LAN or RS232C
  • 500 cd/m2 brightnessand HDR compatibilty will capture the attention of audience in almost any situation
  • Integrated Media Playerallows for audio, video or image playback via USB
  • 24/7 commercial runtimeswith built-in real-time clock and full scheduler capabilities
  • Failover Capabilitieswith full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
  • Energy Star 8.0 Certified Product
  • Full 3 year commercial warrantyto allow for peace of mind and protection of your investment
  • NaViSet Administrator 2Free software solution that greatly eases administration and management of larger display device installations


Product TypeDigital Signage Display
Technical Information
Video Wall CompatibleYes
Bezel Width (Bottom)0.55" (13.90 mm)
Bezel Width (Top)0.55" (13.90 mm)
Bezel Width (Left)0.55" (13.90 mm)
Bezel Width (Right)0.55" (13.90 mm)
Panel TechnologyVertical Alignment (VA)
Operation Hours24 Hours/7 Days
Display & Graphics
Number of Screens1
Viewable Screen Size55" (1397 mm)
Display Screen TypeLCD
Display Resolution3840 x 2160
High Dynamic Range (HDR)Yes
High Dynamic Range (HDR) Type
  • PQ
  • HLG
  • HDR10
Response Time8 ms
Pixel Pitch12.60 mil (0.32 mm)
Aspect Ratio16:9
Horizontal Viewing Angle178°
Vertical Viewing Angle178°
Backlight TechnologyDirect LED
HDCP SupportedYes
OrientationLandscape/Portrait
Video
Scan Format2160p
Dynamic Contrast Ratio8,000:1
Color Depth8-bit+FRC
Brightness500 cd/m²
Network & Communication
EthernetYes
Interfaces/Ports
USBYes
HDMIYes
DisplayPortYes
SerialYes
Number of HDMI Inputs2
RS-232C InputYes
Number of HDMI 2.0 Ports2
Power Description
Power Consumption265 W
Environmental Conditions
Minimum Storage Temperature-4°F (-20°C)
Maximum Storage Temperature140°F (60°C)
Minimum Operating Humidity20%
Maximum Operating Humidity80%
Minimum Storage Humidity10%
Maximum Storage Humidity80%
Physical Characteristics
VESA Mount Standard400 x 400
Mount Type
  • Wall Mountable
  • Table Mount
Height28.06" (712.60 mm)
Width48.89" (1241.80 mm)
Depth2.46" (62.60 mm)
Weight (Approximate)41.40 lb (18778.72 g)
Miscellaneous
Package Contents
  • 55" Ultra High Definition Professional Display
  • 3m Power Cord
  • 2.0m HDMI Cable
  • Wireless Remote Control
  • Batteries
  • Setup Guide
Energy StarYes
Energy Efficiency CertificationENERGY STAR 8.0
ConditionNo
UPC0805736079142
Warranty
Limited Warranty3 Year
