Sharp LD-A1381F Digital Signage Display

Part No. LD-A1381F

by Sharp Electronics

$57971.99

Sharp LD-A1381F Digital Signage Display

11.50 ft (3505.20 mm) LCD - ARM Cortex A55 1.50 GHz - 4 GB - 1920 x 1080 - 16:9 - Direct View LED - 500 cd/m² - 1080p - HDMI - USB - SerialEthernet - Android 13 - Black

Part No. LD-A1381F

by Sharp Electronics

$57971.99
General Information
ManufacturerSharp Electronics
Manufacturer Part NumberLD-A1381F
Brand NameSharp
Product SeriesLD-AF
Product ModelLD-A1381F
Product NameLD-A1381F Digital Signage Display
Marketing Information

Sharp's new LD-AF Series of direct view LED displays offer a streamlined, user-friendly solution that differs from standard LED walls. Unlike traditional direct view LED displays, which often require additional components like external controllers or speakers, Sharp's LD-AF Series features built-in speakers, remote control functionality, and an intuitive interface for easy setup and operation. Designed for simplicity and convenience, these displays provide a unified user experience across Sharp's line of system-on-chip (SoC) displays, and a streamlined installation process. Available in 138" and 165" diagonal sizes, they deliver Full HD (1920x1080) imagery, making them perfect for environments like conference rooms and meeting spaces that need a high-quality, hassle-free display.

  • Full HD (1920x1080) native resolutionwith a 138" class diagonal for crystal clear and immersive imagery
  • Quick and easy installation processwith a single power cable and a hassle-free installation process, the Sharp LD-AF Series can be implemented in as little as two hours
  • Powerful System-on-Chip for versatile functionalitypowered by Android 13 with a high-end integrated media player, as well as support for third-party applications (APKs) as needed
  • Integrated USB-C connectionthat not only allows for DP-Alt mode, but also upstream cababilities for controlling peripherals through the separate USB-A downstream connection
  • NaViSet Administratoris Sharp's proprietary software solution that greatly eases administration and management of larger disply device installations. Control your entire Sharp display ecosystem through this optional software
  • Fully compatiblewith Crestron Connected software as well as Crestron XiO Cloud Service
  • To learn more about Sharp's LD-AF Series,
  • Please contact Sharp or your local AV dealer for information on pricing including installation.
Product TypeDigital Signage Display
Technical Information
Video Wall CompatibleYes
Ingress Protection (IP) RatingIP20
Minimum Color Temperature4940.3°F (2726.8°C)
Maximum Color Temperature16640.3°F (9226.8°C)
Processor & Chipset
Processor ManufacturerARM
Processor TypeCortex A55
Processor Speed1.50 GHz
Processor CoreQuad-core (4 Core)
Memory
Standard Memory4 GB
Display & Graphics
Number of Screens1
Viewable Screen Size11.50 ft (3505.20 mm)
Screen Size Class11.50 ft (3505.20 mm)
Display Screen TypeLCD
Display Resolution1920 x 1080
Pixel Pitch59.06 mil (1.50 mm)
Aspect Ratio16:9
Backlight TechnologyDirect View LED
OrientationLandscape
Module Resolution384 x 216
Maximum LED Life11.4 Year
Pixel Configuration3-in-1 SMD
Video
Scan Format1080p
Dynamic Contrast Ratio6,500:1
Color Depth16-bit
Brightness500 cd/m²
Network & Communication
EthernetYes
Interfaces/Ports
USBYes
HDMIYes
SerialYes
Number of USB 2.0 Ports1
Number of USB 3.0 Ports2
Number of HDMI Inputs3
USB Type-CYes
RS-232C InputYes
Digital Audio Optical OutputYes
Number of HDMI 2.0 Ports3
Software
Operating SystemAndroid 13
Environmental Conditions
Minimum Operating Temperature-4°F (-20°C)
Maximum Operating Temperature104°F (40°C)
Minimum Storage Temperature-4°F (-20°C)
Maximum Storage Temperature113°F (45°C)
Minimum Operating Humidity10%
Maximum Operating Humidity80%
Minimum Storage Humidity10%
Maximum Storage Humidity85%
Physical Characteristics
Color FamilyBlack
Product ColorBlack
Mount TypeWall Mountable
Mount SurfaceWall
Height72.20" (1833.88 mm)
Width10.05 ft (3063.24 mm)
Depth3" (76.20 mm)
Weight (Approximate)304.20 lb (137982.80 g)
Miscellaneous
Package Contents
  • LD-A1381F Digital Signage Display
  • Wall Mount
  • Wireless remote control
  • Power cord
Indoor/OutdoorIndoor
Application/Usage
  • Conference Room
  • Meeting Room
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
ConditionNo
Warranty
Limited Warranty2 Year
