Sharp 165" LD-AF Series All-in-one FHD LED

Part No. LD-A1651F

by Sharp Electronics

$67323.99

Sharp 165" LD-AF Series All-in-one FHD LED

13.75 ft (4191 mm) LCD - ARM Cortex A55 1.50 GHz - 4 GB - 1920 x 1080 - 16:9 - Direct View LED - 500 cd/m² - 1080p - Speakers - HDMI - USB - SerialEthernet - Android 13

Part No. LD-A1651F

by Sharp Electronics

$67323.99
General Information
ManufacturerSharp Electronics
Manufacturer Part NumberLD-A1651F
Brand NameSharp
Product SeriesLD-AF
Product ModelLD-A1651F
Product Name165" LD-AF Series All-in-one FHD LED
Marketing Information

Sharp's new LD-AF Series of direct view LED displays offer a streamlined, user-friendly solution that differs from standard LED walls. Unlike traditional direct view LED displays, which often require additional components like external controllers or speakers, Sharp's LD-AF Series features built-in speakers, remote control functionality, and an intuitive interface for easy setup and operation. Designed for simplicity and convenience, these displays provide a unified user experience across Sharp's line of system-on-chip (SoC) displays, and a streamlined installation process. Available in 138" and 165" diagonal sizes, they deliver Full HD (1920x1080) imagery, making them perfect for environments like conference rooms and meeting spaces that need a high-quality, hassle-free display.

  • Full HD (1920x1080) native resolutionwith a 165" class diagonal for crystal clear and immersive imagery
  • Quick and easy installation processwith a single power cable and a hassle-free installation process, the Sharp LD-AF Series can be implemented in as little as two hours
  • Powerful System-on-Chip for versatile functionalitypowered by Android 13 with a high-end integrated media player, as well as support for third-party applications (APKs) as needed
  • Integrated USB-C connectionthat not only allows for DP-Alt mode, but also upstream cababilities for controlling peripherals through the separate USB-A downstream connection
  • NaViSet Administratoris Sharp's proprietary software solution that greatly eases administration and management of larger disply device installations. Control your entire Sharp display ecosystem through this optional software
  • Fully compatiblewith Crestron Connected software as well as Crestron XiO Cloud Service
Product TypeDigital Signage Display
Technical Information
Speaker Power36 W
Ingress Protection (IP) RatingIP20
Processor & Chipset
Processor ManufacturerARM
Processor TypeCortex A55
Processor Speed1.50 GHz
Processor CoreQuad-core (4 Core)
Memory
Standard Memory4 GB
Display & Graphics
Number of Screens1
Viewable Screen Size13.75 ft (4191 mm)
Screen Size Class13.75 ft (4191 mm)
Display Screen TypeLCD
Display Resolution1920 x 1080
Pixel Pitch74.80 mil (1.90 mm)
Aspect Ratio16:9
Horizontal Viewing Angle80°
Vertical Viewing Angle70°
Backlight TechnologyDirect View LED
OrientationLandscape
Module Resolution320 x 180
Maximum LED Life11.4 Year
Pixel Configuration3-in-1 SMD
Audio
Number of Speakers2
SpeakersYes
Video
Scan Format1080p
Standard Refresh Rate3.84 kHz
Dynamic Contrast Ratio6,500:1
Color Depth16-bit
Brightness500 cd/m²
Network & Communication
EthernetYes
Interfaces/Ports
USBYes
HDMIYes
SerialYes
Number of USB 2.0 Ports1
Number of USB 3.0 Ports2
Number of HDMI Inputs3
USB Type-CYes
RS-232C InputYes
Number of HDMI 2.0 Ports3
Software
Operating SystemAndroid 13
Power Description
Power Consumption2150 W
Environmental Conditions
Minimum Operating Temperature32°F (0°C)
Maximum Operating Temperature104°F (40°C)
Minimum Storage Temperature-4°F (-20°C)
Maximum Storage Temperature140°F (60°C)
Minimum Operating Humidity10%
Maximum Operating Humidity80%
Minimum Storage Humidity10%
Maximum Storage Humidity80%
Physical Characteristics
Mount TypeWall Mountable
Height85.67" (2176.02 mm)
Width12.05 ft (3674.11 mm)
Depth2.96" (75.18 mm)
Weight (Approximate)459 lb (208198.90 g)
Miscellaneous
Package Contents
  • 165" LD-AF Series All-in-one FHD LED
  • Remote control
  • Wall mount
  • Indoor/OutdoorIndoor
    Application/Usage
    • Conference Room
    • Meeting Room
    Environmental ComplianceRestriction of Hazardous Substances (RoHS)
    ConditionNo
    Warranty
    Limited Warranty2 Year
