Optoma ProScene FHDC163 Digital Signage Display

13.58 ft (4140.20 mm) LCD - High Dynamic Range (HDR) - ARM Cortex A76 - 8 GB - 1920 x 1080 - 16:9 - Direct View LED - 700 cd/m² - 1080p - HDMI - USB - Serial - Android 13

Part No. FHDC163

by Optoma Technology

$83664.99

Manufacturer Brochure

Specifications

General Information

Manufacturer	Optoma Technology
Manufacturer Part Number	FHDC163
Brand Name	Optoma
Product Line	ProScene
Product Model	FHDC163
Product Name	ProScene FHDC163 Digital Signage Display
Marketing Information	COMPLETE ALL-IN-ONE DISPLAY SOLUTION Streamlined setup: Using lightweight LED columns, easy tile design, and power from a single, standard 110V outlet. Immersive audio: 120-watt 6-speaker system to ensure everyone in the room hears every word. Integrated operating system: Built-in Android OS with File Manager and local storage for quick and easy access. ROBUST Flip-chip COB (Chip on Board) dvLED TECHNOLOGY Enhanced durability: COB technology provides protection against impacts and improved resilience against dust and scratches when compared to SMD technology. Longer life: Flip-chip architecture removes wire-bonds, enhancing light-efficiency and improved heat dissipation, contributing to a longer life. Pixel perfection: COB LEDs provide a fine pixel pitch and outperforms SMD with unmatched clarity, brightness, and energy efficiency. FLAWLESS IMAGE PRECISION & A SPECTRUM OF VIBRANT HUES Vivid, lifelike colors: Wide DCI-P3 color gamut delivers rich and vibrant visuals. Bright and smooth matte finish: Delivers a bright and consistently crisp image, even at wide viewing angles and in bright environments. High contrast ratio and refresh rate: Exceptional clarity and depth, 15,000:1 contrast ratio and reduced screen tear, flickering and motion blur.
Product Type	Digital Signage Display

Technical Information

Ingress Protection (IP) Rating	IP65
Minimum Color Temperature	3680.3°F (2026.8°C)
Maximum Color Temperature	16280.3°F (9026.8°C)

Processor & Chipset

Processor Manufacturer	ARM
Processor Type	Cortex A76
2nd Processor Manufacturer	ARM
2nd Processor Type	Cortex A55

Memory

Standard Memory	8 GB

Display & Graphics

Number of Screens	1
Viewable Screen Size	13.58 ft (4140.20 mm)
Screen Size Class	13.58 ft (4140.20 mm)
Display Screen Type	LCD
Display Resolution	1920 x 1080
High Dynamic Range (HDR)	Yes
Pixel Pitch	70.87 mil (1.80 mm)
Aspect Ratio	16:9
Backlight Technology	Direct View LED
Maximum LED Life	11.4 Year
LED Type	COB

Video

Scan Format	1080p
Dynamic Contrast Ratio	15,000:1
Color Depth	16-bit
Brightness	700 cd/m²
Color Gamut	92.42% DCI-P3 99.36% Rec. 709

Interfaces/Ports

USB	Yes
HDMI	Yes
Serial	Yes
Number of USB 3.0 Ports	2
Number of HDMI Inputs	4
Number of HDMI Outputs	1
USB Type-C	Yes
RS-232C Input	Yes
Number of Audio Line Out	2
Number of HDMI 2.0 Ports	1

Software

Operating System	Android 13

Power Description

Input Voltage	120 V AC 230 V AC
Average Power Consumption	641 W

Environmental Conditions

Minimum Operating Temperature	14°F (-10°C)
Maximum Operating Temperature	104°F (40°C)

Physical Characteristics

Mount Type	Wall Mountable Stand Mount
Mount Surface	Wall
Height	84.65" (2150.11 mm)
Width	11.91 ft (3629.91 mm)
Depth	1.22" (30.99 mm)
Weight (Approximate)	341.72 lb (155001.58 g)

Miscellaneous

Package Contents	ProScene FHDC163 Digital Signage Display Remote Control Tile Removal Tool Magnetic Front Plate Removal Tool Wall Mount Bracket Power Cord (3m)
Application/Usage	Corporate Education Retail Hospitality House of Worship
Condition	No

Warranty

Limited Warranty	3 Year
