POS-X EVO-PT3-2GUS Direct Thermal Printer - Monochrome - Wall Mount - Receipt Print - USB - Serial - With Cutter - Black

2.84" Print Width - 200 mm/s Mono - 180 x 180 dpi - 3.15" (80.01 mm) Label WidthAutomatic Cutting

Part No. 911LB480300333

by POS-X LLC

$289.99

Manufacturer Brochure

Specifications

General Information

Manufacturer	POS-X LLC
Manufacturer Part Number	911LB480300333
Brand Name	POS-X
Product Model	EVO-PT3-2GUS
Product Name	EVO PT3 : EVO Green Thermal Receipt,USB,Serial
Marketing Information	POS-X EVO PT3 : EVO Green Thermal Receipt Printer (USB, Serial): The EVO Green Thermal Receipt Printer is one of our most efficient receipt printers. Engineered to operate day-in and day-out in the harshest of environments, the EVO Green provides the steadfast performance you need while using a fraction of the energy. Perfect for high volume retail and hospitality operations, the EVO Green features quick receipt printing, JamFree Autocutter Technology, and is backed by the best warranty in the industry. 3 YEAR ADVANCE REPLACE WARRANTY: Call POS-X 24/7 US based support and if we can't fix it over the phone, we will ship a replacement unit to arrive within two days. Upgrades to overnight and/or 5 years available (Part #s: ZOE-CRW3, ZOE-CRW5, ZWE-CRW). TOP RATED PERFORMANCE: Our flagship printer, the EVO HiSpeed not only comes standard with industry leading specifications, it also beats the competition in price and value. INCREDIBLY FAST PRINTING: Output receipts at at incredible 12 inches per second (300mm), saving valuable time at checkout. COMPATIBILITY: With the ability to connect via USB, Serial, Ethernet or Parallel, the EVO HiSpeed is fully ESC/POS and OPOS compatible. WALL MOUNTABLE: Convenient mounting capabilities allow for optimal printer placement. EASY PAPER LOADING: Easy drop-in thermal paper loading
Product Type	Direct Thermal Printer

Technical Information

Recommended Use	Receipt Print
Print Color Capability	Monochrome
Maximum Mono Print Speed	200 mm/s
Maximum Print Resolution (dpi)	180 x 180
Maximum Print Width	2.84"
Barcode Symbology Supported	EAN-8 EAN-13 Code 39 ITF UPC-A Codabar Code 93 Code 128 PDF-417
Print Technology	Direct Thermal

Interfaces/Ports

Serial Port	Yes
USB	Yes

Cutter

Cutter	Yes
Cutting Method	Automatic

Media Types & Handling

Media Type	Receipt Thermal Paper
Media Sensor	Out Of Paper Sensor Paper Low Sensor Cover Open Sensor
Media Thickness	3.5 mil
Maximum Roll Diameter	3.2"
Maximum Label Width	3.15" (80.01 mm)
Label Core Size	0.49" (12.50 mm)

Fonts & Emulation

Language Emulation	ESC/POS OPOS

Power Description

Power Source	Power Adapter
Input Voltage	24 V DC

Physical Characteristics

Form Factor	Wall Mount
Color Family	Black
Product Color	Black
Height	6.10" (154.94 mm)
Width	6.10" (154.94 mm)
Depth	8" (203.20 mm)
Weight (Approximate)	1.68 kg

Miscellaneous

Package Contents	EVO PT3 : EVO Green Thermal Receipt,USB,Serial Quick Start Guide AC Power Adapter Sample Paper Roll Interface Cable(s)
Power Adapter Included	Yes
Platform Supported	PC
Certifications & Standards	FCC UL/cUL CE-LVD CE-EMCD CE NOM
Energy Star	Yes
Environmentally Friendly	Yes
COO	CN
Condition	No

Warranty

Limited Warranty	3 Year
