Barco Nio Color MDNC-3421 QXGA LCD Monitor - 4:3

21.3" Viewable - LED Backlight - 2048 x 1536 - 1.07 Billion Colors - 900 cd/m² - 20 ms - DVI - DisplayPort - USB Hub

Part No. K9602856

by Barco

$6718.99

Specifications

General Information

Manufacturer	Barco
Manufacturer Part Number	K9602856
Brand Name	Barco
Product Line	Nio Color
Product Model	MDNC-3421
Product Name	Nio Color 3MP (MDNC-3421) 3MP High-bright Color Display
Marketing Information	Nio Color 3MP is a 3 megapixel high-bright color display system with LED backlights, providing excellent image quality for confident diagnoses. Its exceptional brightness (calibrated at 500 cd/m²) helps you discern even the tiniest detail - even after many years of use. The best 3MP color solution on the market The new Nio Color 3MP offers the best image quality in the market for a 3MP color solution. Its high brightness and high contrast ratio enable you to unveil even the subtlest details and make accurate diagnoses. With the integrated smart features, you can easily take control and improve your productivity. SpotView^TM, for example, allows you to focus on an area of interest to unveil even more details. And with DimView^TM, any auxiliary displays can be automatically dimmed. The Nio Color 3MP is also an excellent solution for radiologists who want to angle their desktop: it lets you choose your preferred viewing angle and offers highly ergonomic display configuration. Stable image quality, durable investment Using Barco's integrated front sensor, the Nio Color 3MP works perfectly with Barco's online MediCal QAWeb solution for automated Quality Assurance and calibration. QAWeb guarantees stable DICOM images throughout the display's lifetime. By default, Barco displays are equipped with a protective cover to safeguard your investment. Thanks to the high-performance LED backlights, the Nio Color 3MP requires less power, even at higher calibrated luminance. This has a positive impact on both maintenance and operational costs. Ultimate peace of mind Barco is the only company that provides complete system solutions, from display and controllers to workflow tools and calibration via QAWeb. All components are covered by our full 5-year warranty. At product release, Barco extensively tests the displays compatibility with all major PACS applications. Features High-bright and power-efficient LED backlights Accurate grayscale and color rendering Front sensor and MediCal QAWeb for easy DICOM conformance High-performance 3D rendering with full 3D, OpenGL and DirectX support
Product Type	LCD Monitor

Technical Information

Number of Screens	1
Viewable Screen Size	21.3"
Screen Mode	QXGA
Response Time	20 ms
Aspect Ratio	4:3
Backlight Technology	LED

Video

Maximum Resolution	2048 x 1536
Color Supported	1.07 Billion Colors
Contrast Ratio	1,400:1
Brightness	900 cd/m²

Interfaces/Ports

DVI	Yes
USB	Yes
DisplayPort	Yes

Built-in Devices

Built-in Devices	USB Hub

Power Description

Operating Power Consumption	50 W

Physical Characteristics

VESA Mount Compatible	Yes
VESA Mount Standard	100 x 100
Height	19.33" (491 mm)
Width	14.88" (378 mm)
Depth	3.31" (84 mm)
Height with Stand	24.72" (628 mm)
Width with Stand	14.88" (378 mm)
Depth with Stand	9.25" (235 mm)
Weight (Approximate)	13.67 lb (6200 g)
Weight with Stand (Approximate)	24.69 lb (11200 g)

Miscellaneous

Package Contents	Nio Color 3MP (MDNC-3421) 3MP High-bright Color Display User guide Documentation disc System disc 1 x DisplayPort cable Mains cables Adaptor plug USB 2.0 cable External power supply
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Condition	No

Warranty

Limited Warranty	5 Year
