• Mounts into a single-gang electrical box (not included.)
• The backlit bar indicator features 20 LEDs.
• LEDs can be set for high or low intensity.
• Includes (8) changeable button labels that can be printed on a laser printer.
• A built-inn IR sensor enables easy connections to the ControlBridge Processor.

• Wall Mountable
• Gang Box Mount

• ControlBridge 8-Button Wallmount Keypad
• 1 x Back Box (not electrical)
• Printable Foil Label
• 2 x Mounting Screws
• Mounting Bracket
• Connection Cable

• Communications: RS-485 serial
• Controls: (8) buttons with red back light
• Enclosure: Single-gang, stainless-steel front panel, IP30 rated
• Environmental Temperature: 50° to 104° F (0° to 40° C);
• Humidity: 10% to 90% non-condensing
• Labels: Transparent foil; User printed
• Power: 24 VDC, 3 W

This product works with:

• Single-Seat License for Mobile Device
• ControlBridge Processor 100
• ControlBridge Processor 200

• Waste Electrical and Electronic Equipment Directive (WEEE)
• Restriction of Hazardous Substances (RoHS)
