Elo 1593L Open-frame LCD Touchscreen Monitor - 16:9 - 10 ms
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | Elo Touch Solutions, Inc |
| Manufacturer Part Number | E331799 |
| Brand Name | Elo |
| Product Model | 1593L |
| Product Name | 1593L 15.6" Open Frame Touchscreen (Rev B) |
| Marketing Information | The Elo 1593L 15-inch open-frame LCD touch display features a slim design and narrow outside dimensions due to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact touch display is designed for touch with proven Elo expertise and reliability built in. The 1593L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Instantly grabbing and holding users' attention, the 15.6-inch open frame is perfect for kiosks, casino and amusement, retail self-service, and industrial automation environments. Easily integrated.The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected as well as backwards compatibility where we can make it possible to help minimize additional enclosure costs. Touch ready.Available with a choice of industry leading touch technologies, in single- or multi-touch technology, including IntelliTouch® single-touch surface acoustic wave (SAW) touchscreen technology, and our latest zero-bezel TouchPro™ PCAP two-glass solution (2GS) technology that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves. Commercial-grade.The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution, with touch integrated from the start. Using our touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life-testing processes. All our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF. Other features.
|
| Product Type | Open-frame LCD Touchscreen Monitor |
| Viewable Screen Size | 15.6" |
| Screen Mode | WXGA |
| Response Time | 10 ms |
| Aspect Ratio | 16:9 |
| Mount Type |
|
| Backlight Technology | LED |
| Maximum Resolution | 1366 x 768 |
| Color Supported | 16.7 Million Colors |
| Contrast Ratio | 500:1 |
| Brightness | 300 cd/m² |
| Touchscreen Type | Projected Capacitive |
| Multi-touch Screen | Yes |
| HDMI | Yes |
| USB | Yes |
| VGA | Yes |
| DisplayPort | Yes |
| Operating Power Consumption | 13.60 W |
| VESA Mount Compatible | Yes |
| Product Color | Black |
| Height | 9.53" (242.06 mm) |
| Width | 15.54" (394.72 mm) |
| Depth | 1.71" (43.43 mm) |
| Weight (Approximate) | 6.70 lb (3039.07 g) |
| Package Contents |
|
| Certifications & Standards | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance |
|
| COO | CN |
| Condition | No |
| Limited Warranty | 3 Year |
