Elo 2494L Open-frame LCD Touchscreen Monitor - 16:9 - 16 ms
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | Elo Touch Solutions, Inc |
| Manufacturer Part Number | E329825 |
| Brand Name | Elo |
| Product Model | 2494L |
| Product Name | 2494L 23.8" Open Frame Touchscreen (Rev B) |
| Marketing Information | The Elo 2494L 24-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions due to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact display is designed for touch, with proven Elo expertise and reliability built in. The 2494L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Featuring a brilliant wide viewing angle panel, the open-frame touchscreen instantly grabs and holds the users' attention for kiosks, casino and amusement, retail self-service, and industrial automation environments. Easily integrated.The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected as well as backwards compatibility where we can make it possible to help minimize additional enclosure costs. Touch ready.Available with a choice of industry-leading touch technologies, in single-, dual- or multi-touch technology, including IntelliTouch® surface acoustic wave (SAW) with single- and dual-touch, IntelliTouch single-touch SAW with zero-bezel, and our latest multi-touch TouchPro™ PCAP two-glass solution (2GS) technology has a zero-bezel that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves. Commercial-grade.The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution with touch integrated from the start. Using our own touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life testing processes. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF. Other features.
|
| Product Type | Open-frame LCD Touchscreen Monitor |
| Viewable Screen Size | 23.8" |
| Screen Mode | Full HD |
| Response Time | 16 ms |
| Aspect Ratio | 16:9 |
| Mount Type | Front Mount |
| Backlight Technology | LED |
| Maximum Resolution | 1920 x 1080 |
| Color Supported | 16.7 Million Colors |
| Contrast Ratio | 3,000:1 |
| Brightness | 250 cd/m² |
| Touchscreen Type | IntelliTouch Surface Wave |
| Multi-touch Screen | Yes |
| HDMI | Yes |
| USB | Yes |
| VGA | Yes |
| DisplayPort | Yes |
| Operating Power Consumption | 23.70 W |
| VESA Mount Compatible | Yes |
| Product Color | Black |
| Height | 13.46" (341.88 mm) |
| Width | 22.44" (569.98 mm) |
| Depth | 1.46" (37.08 mm) |
| Weight (Approximate) | 14.10 lb (6395.65 g) |
| Package Contents |
|
| Certifications & Standards | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance |
|
| COO | CN |
| Condition | No |
| Limited Warranty | 3 Year |
