Supermicro SuperStorage 5029P-E1CTR12L Server Barebone System - 2U Rack-mountable - Socket P LGA-3647 - 1 x Processor Support
Intel C622 Chip - 2 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 8 Total Memory Slots - 12Gb/s SAS RAID Supported, Serial ATA/600 Controller - 12 3.5" Bay(s) - 10 SATA Interface(s) - Processor Support (Xeon Gold, Xeon Platinum, Xeon Bronze, Xeon Silver) - 10 Gigabit Ethernet - Intel Optane Memory Ready - 5 USB 3.0 Port(s) - 2 x 800 W - 3 Year
$3610.99
On back-order, will ship once in-stock
- All Locations: (0+)
General Information
| Manufacturer | Supermicro Computer, Inc |
| Manufacturer Part Number | SSG-5029P-E1CTR12L |
| Brand Name | Supermicro |
| Product Line | SuperStorage |
| Product Model | 5029P-E1CTR12L |
| Product Name | SuperStorage 5029P-E1CTR12L (Black) |
| Product Type | Server Barebone System |
Processor
| Number of Processors Supported | 1 |
| Processor Socket | Socket P LGA-3647 |
| Processor Supported |
|
| 64-bit Processing | Yes |
Chipset
| Chipset Manufacturer | Intel |
| Chipset Model | C622 |
Memory
| Maximum Memory Supported | 2 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2933/PC4-23466 |
| Total Number of Memory Slots | 8 |
| Intel Optane Memory Ready | Yes |
Controllers
| Controller Type |
|
| RAID Supported | Yes |
Network & Communication
| Ethernet Technology | 10 Gigabit Ethernet |
I/O Expansions
| Number of 3.5" Bays | 12 |
| Total Number of Expansion Slots | 4 |
| Number of PCI Express x4 Slots | 1 |
| Number of PCI Express x8 Slots | 2 |
| Number of PCI Express x16 Slots | 1 |
Interfaces/Ports
| Total Number of USB Ports | 13 |
| Number of USB 3.0 Ports | 5 |
| Number of SATA Interfaces | 10 |
Power Description
| Input Voltage |
|
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 800 W |
Physical Characteristics
| Color Family | Black |
| Product Color | Black |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.50" (88.90 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 25.60" (650.24 mm) |
| Weight (Approximate) | 34 lb (15422.14 g) |
Miscellaneous
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Condition | No |
Warranty
| Limited Warranty | 3 Year |
