Advantech IDS-3112N-60XGA1E 12" Class Open-frame LCD Touchscreen Monitor - 4:3 - 16 ms
12.1" Viewable - 5-wire Resistive - 1024 x 768 - XGA - 16.2 Million Colors - 600 cd/m² - LED Backlight - DVI - USB - VGA - 2 Year
$482.99
On back-order, will ship once in-stock
- All Locations: (0+)
General Information
| Manufacturer | Advantech Co., Ltd |
| Manufacturer Part Number | IDS-3112N-60XGA1E |
| Brand Name | Advantech |
| Product Series | IDS-3112 |
| Product Model | IDS-3112N-60XGA1E |
| Product Name | IDS-3112N-60XGA1E Open Frame LCD Touchscreen Monitor |
| Marketing Information | The Advantech IDS-3112 Open Frame Monitor Series offer ultra slim design supporting a 12.1" 1024 x 768 and 800 x 600 pixels TFT LCD screen, with -20 ~ 60° C wide operating temperature, and optional resistive touchscreen. The series supports rear and VESA mounting and is ideal for different embedded applications. |
| Product Type | Open-frame LCD Touchscreen Monitor |
Technical Information
| Screen Size Class | 12" |
| Viewable Screen Size | 12.1" |
| Screen Mode | XGA |
| Response Time | 16 ms |
| Aspect Ratio | 4:3 |
| Mount Type | Rear Mount |
| Backlight Technology | LED |
Video
| Maximum Resolution | 1024 x 768 |
| Color Supported | 16.2 Million Colors |
| Native Contrast Ratio | 700:1 |
| Brightness | 600 cd/m² |
Touchscreen Information
| Touchscreen Type | 5-wire Resistive |
Interfaces/Ports
| DVI | Yes |
| USB | Yes |
| VGA | Yes |
| Number of USB Ports | 1 |
Power Description
| Operating Power Consumption | 36 W |
Physical Characteristics
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Height | 9.92" (252 mm) |
| Width | 12.60" (320 mm) |
| Depth | 1.21" (30.70 mm) |
| Weight (Approximate) | 3.48 lb (1580 g) |
Miscellaneous
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Condition | No |
Warranty
| Limited Warranty | 2 Year |
