Advantech IDS-3118WP-30HDA1E 19" Class Open-frame LCD Touchscreen Monitor - 5 ms
18.5" Viewable - Projected Capacitive - 1366 x 768 - HD - 16.7 Million Colors - 300 cd/m² - LED Backlight - DVI - HDMI - USB - VGA - 2 Year
$768.99
On back-order, will ship once in-stock
- All Locations: (0+)
General Information
| Manufacturer | Advantech Co., Ltd |
| Manufacturer Part Number | IDS-3118WP-30HDA1E |
| Brand Name | Advantech |
| Product Series | IDS-3118W |
| Product Model | IDS-3118WP-30HDA1E |
| Product Name | IDS-3118WP-30HDA1E Open Frame LCD Touchscreen Monitor |
| Marketing Information | The Advantech IDS-3118W Open Frame Monitor Series offer ultra slim design supporting a 18.5" 1366 x 768 pixels TFT LCD screen, with 0 ~ 55° C operating temperature, and optional resistive and projective capacitive touchscreen. The series supports rear and VESA mounting and is ideal for different embedded applications. |
| Product Type | Open-frame LCD Touchscreen Monitor |
Technical Information
| Screen Size Class | 19" |
| Viewable Screen Size | 18.5" |
| Screen Mode | HD |
| Response Time | 5 ms |
| Mount Type | Rear Mount |
| Backlight Technology | LED |
Video
| Maximum Resolution | 1366 x 768 |
| Color Supported | 16.7 Million Colors |
| Native Contrast Ratio | 1,000:1 |
| Brightness | 300 cd/m² |
Touchscreen Information
| Touchscreen Type | Projected Capacitive |
Interfaces/Ports
| DVI | Yes |
| HDMI | Yes |
| USB | Yes |
| VGA | Yes |
| Number of USB Ports | 1 |
Physical Characteristics
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Height | 12.01" (305 mm) |
| Width | 18.82" (478 mm) |
| Depth | 1.41" (35.90 mm) |
| Weight (Approximate) | 10.36 lb (4700 g) |
Miscellaneous
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Condition | No |
Warranty
| Limited Warranty | 2 Year |
