QNAP Dual CPU and Dual OS System for Mission-critical Applications
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | TDS-16489U-SE1-R2-US |
| Brand Name | QNAP |
| Product Series | TDS-16489U R2 |
| Product Model | TDS-16489U-SE1-R2 |
| Product Name | Dual CPU and Dual OS System for Mission-critical Applications |
| Marketing Information | Dual CPU and dual OS system: A perfect NAS solution for high-performance computing and storage by using the QES or QTS operating system Integrating an application server and storage server into one system, the next-generation TDS-16489U R2 also provides you with the option of using either QES (an enterprise-grade OS that provides efficient and reliable storage for mission-critical tasks) or QTS (a feature-rich OS for storage and diverse application servers). Whether being used as a file server, virtualization server, VDI, medium-sized data center, video streaming, surveillance storage, and efficient file backup & recovery, the flexible TDS-16489U R2 with dual CPU and dual OS options is your ideal solution.
Multiplied computing power with dual Intel® Xeon® E5 processors Built for data-intensive applications and demanding workloads, the TDS-16489U R2 is powered by dual Intel® Xeon® E5-2600 v4 multi-core processors, up to 1 TB quad-channel DDR4 2133MHz RDIMM/LRDIMM RAM (Long-DIMM x16), and 12Gb/s SAS drive support to deliver outstanding performance for data transmission and applications. While providing the power to handle CPU-demanding tasks and everyday application needs such as virtualization, video surveillance, and media streaming, the TDS-16489U R2's unrivaled performance provides the ability for businesses to improve their Big Data computing to explore greater business opportunities. Convertible NAS that supports two operating systems The TDS-16489U R2 provides flexibility to choose from two operating systems, enabling businesses to deploy an operating system that fits their needs and goals in different stages. Abundant I/O capabilities with PCIe expansion The TDS-16489U R2 features four PCIe slots (3 x PCIe Gen3 x8, 1 x PCIe Gen3 x16) that allow for the usage of various expansion cards to expand application potential.
|
| Product Type | SAN/NAS Storage System |
| Number of Hard Drives Supported | 16 |
| Number of Hard Drives Installed | No |
| Number of Solid State Drive Supported | 20 |
| Number of Solid State Drive Installed | No |
| Flash Memory Capacity | 4 GB |
| Number of Processors Installed | 2 |
| Processor Type | Xeon |
| Processor Model | E5-2620 v4 |
| Processor Core | Octa-core (8 Core) |
| Processor Speed | 2.10 GHz |
| Standard Memory | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Ethernet Technology | 10 Gigabit Ethernet |
| Number of Total Expansion Bays | 20 |
| Number of 2.5" Bays | 4 |
| Number of 2.5"/3.5" Bays | 16 |
| Total Number of Expansion Slots | 8 |
| Expansion Slot Type |
|
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD |
| Total Number of USB Ports | 4 |
| Number of USB 3.0 Ports | 4 |
| Network (RJ-45) | Yes |
| Operating System | QES/QTS 4.3.6 |
| Protocols |
|
| Maximum Power Supply Wattage | 770 W |
| Redundant Power Supply | Yes |
| Height | 5.15" (130.80 mm) |
| Width | 17.48" (444 mm) |
| Depth | 29.29" (744 mm) |
| Form Factor | Rack-mountable |
| Rack Height | 3U |
| Weight (Approximate) | 49.43 lb (22420 g) |
| Package Contents |
|
| Condition | No |
| UPC | 885022017522 |
