Supermicro SuperStorage 6029P-E1CR24L Server Barebone System - 2U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | Supermicro Computer, Inc |
| Manufacturer Part Number | SSG-6029P-E1CR24L |
| Brand Name | Supermicro |
| Product Line | SuperStorage |
| Product Model | 6029P-E1CR24L |
| Product Name | SuperStorage 6029P-E1CR24L (Black) |
| Marketing Information | Supermicro SuperStorage systems offer a broad portfolio of choice in storage subsystems ranging from low-latency NVMe systems, density-optimized systems with 2.5" or 3.5" SAS3/SATA3 storage media, to JBODs and JBOFs for economical storage expansion. The Supermicro SuperStorage systems include no-compromise designs with 2U, 3U, and 4U form factors using 2.5" or 3.5" SSDs/HDDs; plus innovative 1U Petabyte scale All-Flash NVMe systems with industry standard U.2/NF1/EDSFF drives. SuperStorage servers support up to: 6TB DDR4-2933MHz memory, PCI-E 3.0 slots, NVMe, flexible networking options such as 10G SFP+, 10GBase-T LAN ports and IPMI 2.0 and KVM with dedicated LAN, and have support for 2nd generation Intel® Xeon® Scalable processors as well as Intel® Optane™ DC Persistent Memory. Supermicro SuperStorage solutions present a number of key benefits to customers working with CPU Intensive Storage, Virtual Storage, Single Instance Storage and Data Deduplication, Data Replication and Business Continuity, and Virtual Tape Library customer environments. |
| Product Type | Server Barebone System |
| Number of Processors Supported | 2 |
| Processor Socket | Socket P LGA-3647 |
| Processor Supported |
|
| 64-bit Processing | Yes |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Maximum Memory Supported | 6 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2933/PC4-23466 |
| Total Number of Memory Slots | 24 |
| Intel Optane Memory Ready | Yes |
| Controller Type |
|
| RAID Supported | Yes |
| Ethernet Technology | Ethernet |
| Number of Total Expansion Bays | 26 |
| Number of 3.5" Bays | 24 |
| Total Number of Expansion Slots | 4 |
| Number of PCI Express x8 Slots | 1 |
| Number of PCI Express x16 Slots | 2 |
| Total Number of USB Ports | 3 |
| Number of USB 3.0 Ports | 2 |
| Number of SATA Interfaces | 8 |
| Input Voltage |
|
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 1.60 kW |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.50" (88.90 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 30" (762 mm) |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Condition | No |
| Limited Warranty | 1 Year |
