QNAP Enterprise ZFS NAS ES2486DC-2142IT-128G SAN/NAS Storage System
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | ES2486DC-2142IT-128G-US |
| Brand Name | QNAP |
| Product Line | Enterprise ZFS NAS |
| Product Model | ES2486DC-2142IT-128G |
| Product Name | Enterprise ZFS NAS ES2486DC-2142IT-128G SAN/NAS Storage System |
| Marketing Information | ES2486dc Powerful and cost-efficient Intel® Xeon® D based Enterprise ZFS NAS, optimized for inline deduplication and all-flash applications The ES2486dc Enterprise ZFS NAS is QNAP's first high-availability NAS with all-flash arrays and dual active controllers. Powered by an Intel® Xeon® D-2142IT 8 cores/16 threads processor, the ES2486dc supports up to 24 x 2.5-inch SAS 12Gbps SSDs and provides excellent I/O throughputs. Random write performance for all-flash arrays is further driven by the flash-optimized QES 2.1.1 operating system that comes pre-installed on the ES2486dc. The QES uses ZFS to support logical volume management; block-based inline data deduplication and inline compression reduce I/O and SSD storage consumption, which significantly extends SSD lifespan with higher price-performance ratio for all-flash storage arrays. Coupled with near-limitless snapshots and SnapSync for data protection, the QES-based ES2486dc fulfills demanding business applications, such as mission-critical file servers, virtualization servers, VDI, medium-sized data center, video streaming, surveillance storage, and efficient file backup and recovery.
|
| Product Type | SAN/NAS Storage System |
| Number of Hard Drives Supported | 24 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 24 |
| Number of Solid State Drive Installed | 0 |
| Flash Memory Capacity | 4 GB |
| Processor Manufacturer | Intel |
| Processor Type | Xeon |
| Processor Model | D-2142IT |
| Processor Core | Octa-core (8 Core) |
| Processor Speed | 1.90 GHz |
| Standard Memory | 128 GB |
| Memory Technology | DDR4 SDRAM |
| Ethernet Technology |
|
| Number of Total Expansion Bays | 24 |
| Number of 2.5" Bays | 24 |
| Total Number of Expansion Slots | 6 |
| Expansion Slot Type |
|
| Number of Controllers | 2 |
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60, JBOD, RAID-TP |
| Total Number of USB Ports | 2 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 3 |
| Operating System | QES 2.1.1 |
| Protocols |
|
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 700 W |
| Redundant Power Supply | Yes |
| Height | 3.48" (88.39 mm) |
| Width | 19.02" (483.11 mm) |
| Depth | 21.46" (545.08 mm) |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Weight (Approximate) | 60.43 lb (27410.59 g) |
| Package Contents |
|
| Condition | No |
| UPC | 0885022018529 |
| Limited Warranty | 5 Year |
