Elo 1002L 10" Class WXGA LED Monitor - 16:10 - Black
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | Elo Touch Solutions, Inc |
| Manufacturer Part Number | E324341 |
| Brand Name | Elo |
| Product Model | 1002L |
| Product Name | 1002L Widescreen LED Monitor |
| Marketing Information | Elo's 1002LTouchscreen Monitor The Elo 1002L Touchscreen Monitor is designed with the same seamless style that spans across the entire line up of 02-Series Monitors. With a compact form factor and clean design for easy integration, the 1002L offers the flexibility to install as a traditional POS terminal or a customer facing point of interaction - making it well-suited for point-of-sale, self-service, signage and hospitality applications. And with a variety of peripherals, the monitor can be transformed to meet the demands of almost any blueprint. Single Cable Connection The 1002L provides a USB Type-C interface that provides touch, video and power. By reducing the number of cables required for any set up from 3 to 1, installation and servicing is a breeze. In case your PC isn't equipped with USB Type-C yet, you can still use traditional HDMI or VGA to connect to your PC. One for You.One for Your Customers. The 02-Series offers dual functionality. Use it as a traditional POS terminal or customer facing display - or BOTH! Start increasing brand loyalty and customer satisfaction by offering your customers a point of interaction to review transactions, participate in loyalty programs or see the latest promotion. Well-Suited for... Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic. Elo Edge Connect™ Lets You do More! Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripheral options. Whether for endless aisle, self-order or collaboration applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change! EMV Cradles The ability to take payment is essential to complete a transaction. The 1002L offers compatible EMV cradles to securely mount an EMV Payment device directly to the display. Barcode Scanner Enhance POS terminals and price-checker applications by coupling a high-performance barcode scanner onto the Elo touchscreen. MSR Elo offers the flexibility of integrating payment devices, including a Magtek 3-track encryptable MSR payment terminal. Mount with Flexibility Customers demand a seamless shopping experience from their first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party kiosk enclosures, the touchscreens can be integrated with ease. Brilliant Displays from 7 to 27-inches The brilliant touchscreens with Elo's industry-leading TouchPro® PCAP technology offer wide viewing angles with impeccable image clarity, resolution, and light transmission for accurate touch response and vivid images. With up to 10 touches enabled, the 02-Series Monitors, provide a tablet-like experience. Built-to-Last The 02-Series Touchscreen Monitors deliver the quality and reliability Elo is known for and are backed by our 3-year standard warranty with an optional extension to 5-years. We design, build, and stand by the complete solution, with touch integrated from the start. |
| Product Type | LED Monitor |
| Number of Screens | 1 |
| Screen Size Class | 10" |
| Viewable Screen Size | 10.1" |
| Screen Mode | WXGA |
| Panel Technology | Thin Film Transistor (TFT) |
| Response Time | 29 ms |
| Response Time Details | 29ms Typical |
| Aspect Ratio | 16:10 |
| Horizontal Viewing Angle | 170° |
| Vertical Viewing Angle | 170° |
| Mount Type |
|
| Backlight Technology | LED |
| Features |
|
| Horizontal Frequency | 31.50 kHz to 82 kHz |
| Vertical Frequency | 60 Hz |
| Ingress Protection (IP) Rating | IPX1 |
| Impact Protection (IK) Rating | IK04 |
| Active Display Area (H x V) | 8.54" (216.90 mm) x 5.34" (135.60 mm) |
| Maximum Resolution | 1280 x 800 |
| Standard Refresh Rate | 60 Hz |
| Color Supported | 262,000 Colors |
| Native Contrast Ratio | 800:1 |
| Brightness | 350 cd/m² |
| Number of Speakers | 2 |
| Speakers | Yes |
| HDMI | Yes |
| USB | Yes |
| VGA | Yes |
| USB Type-C | Yes |
| Total Number of HDMI Ports | 1 |
| Number of USB Ports | 4 |
| Number of VGA Ports | 1 |
| Total Number of USB Type-C Ports | 1 |
| Operating Temperature Range | 32°F (0°C) to 104°F (40°C) |
| Operating Humidity Range | 20% to 80% (Non-condensing) |
| Operating Power Consumption | 7.43 W |
| Standby Power Consumption | 1.26 W |
| Off-Mode Power Consumption | 200 mW |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 75 x 75 |
| Color Family | Black |
| Color | Black |
| Height | 6.99" (177.50 mm) |
| Width | 10.03" (254.80 mm) |
| Depth | 1.14" (29 mm) |
| Weight (Approximate) | 1.95 lb (884.51 g) |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Energy Efficiency Compliance | Korea E-Standby |
| Environmental Compliance |
|
| Condition | No |
| UPC | 0843173126845 |
| Limited Warranty | 3 Year |
