Alogic MX3 Docking Station
for Monitor, Notebook, Smartphone - Memory Card Reader - SD, microSD - 135 W - USB Type C - 3 Displays Supported - 4K, 5K - 3840 x 2160 - 1 x USB 3.1 Type-C Ports - 3 x USB Type-A Ports - USB Type-A - USB Type-C - 1 x RJ-45 Ports - Network (RJ-45) - DisplayPort - Black, Space Gray - Wired - macOS, Windows - 100W
$310.99
On back-order, will ship once in-stock
- All Locations: (0+)
- Toronto, ON (5+)
General Information
| Manufacturer | Alogic |
| Manufacturer Part Number | DUPRMX3WW |
| Brand Name | Alogic |
| Product Model | MX3 |
| Product Name | MX3 Docking Station |
| Marketing Information | SIMPLIFIED CONNECTIVITY- DP Alt. Mode Technology The MX3 makes multi-display set ups simple. Featuring DP Alt Mode technology, it connects directly with up to three displays and multiple other accessories. No need to install drivers or software. Plug in and go. SINGLE 5K DISPLAY WITH MAC The MX3 is a powerful docking station for Mac users seeking to add a dazzling, ultra-high resolution display for their desk set up. TRIPLE 4K DISPLAYS WITH WINDOWS Windows users can plug into the MX3 to run up to three ultra-high resolution external displays. |
| Product Type | Docking Station |
Technical Information
| Connectivity Technology | Wired |
| Device Supported |
|
| Memory Card Reader | Yes |
| Memory Card Supported |
|
| Number of Displays Supported | 3 |
| Screen Mode Supported |
|
| Supported Resolutions | 3840 x 2160 |
Interfaces/Ports
| Host Interface | USB Type C |
| Number of USB 3.1 Type-C Ports | 1 |
| Number of USB 3.1 Gen 1 Type-A Ports | 3 |
| Number of USB Type-A Ports | 3 |
| USB Type-A | Yes |
| USB Type-C | Yes |
| USB Type-C Detail | 1 x USB-C 3.1Gen 2(10G) BC 1.2 and Apple Charging Support |
| Network (RJ-45) | Yes |
| Number of RJ-45 Ports | 1 |
| Number of DisplayPort Outputs | 3 |
| DisplayPort | Yes |
| DisplayPort Version | 1.4 |
| Headphone/Microphone Combo Port | Yes |
| USB Power Delivery | 100W |
Software
| Operating System Supported |
|
Power Description
| Maximum Power Supply Wattage | 135 W |
Physical Characteristics
| Color Family | Dual Color |
| Product Color |
|
| Height | 1.04" (26.50 mm) |
| Width | 7.48" (190 mm) |
| Depth | 3.54" (90 mm) |
| Weight (Approximate) | 1.18 lb (535 g) |
Miscellaneous
| Package Contents | |
| Compatibility | Compatible with all computers with a USB-C port. |
| Brand Compatibility |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Condition | No |
| UPC | 9350784023834 |
Warranty
| Limited Warranty | 2 Year |
