Asus ExpertCenter PN52-BB5000X1TD-NL Barebone System - Mini PC - 1 x Processor Support - Ryzen 5 5600H 3.20 GHz
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | 90MR00R2M00130 |
| Brand Name | Asus |
| Product Line | ExpertCenter |
| Product Series | PN52 |
| Product Model | PN52-BB5000X1TD-NL |
| Product Name | ExpertCenter PN52-BB5000X1TD-NL Barebone System |
| Marketing Information | Ultra-compact mini PC with AMD Ryzen™ 5000H series processors and AMD Radeon ™ Graphics, supports Quad-4K displays and 8K resolution, 2x PCIe® Gen3 x4 M.2 NVMe® SSD, 2.5 Gb LAN, WiFi 6E
ASUS ExpertCenter PN52 is powered by the latest AMD Ryzen™ 5000H series processor for smooth and powerful multitasking. In PCMark 10 and Cinebench benchmark testing, the Ryzen 5000H delivered a 17.4% boost in overall performance, and up to 23.4% improvement in singlethread computing performance compared to the previous generation processor. Graphics Performance ASUS ExpertCenter PN52 gets a significant graphical boost with Radeon™ Graphics to deliver crisp, clear visuals that are way ahead of its class. It delivers a marked improvement, raising its score from 15% in 3DMark Fire Strike to 23.6% in the 3DMark Night Raid performance benchmarks. 4K Resolution & Quad Display Support ASUS ExpertCenter PN52 can support up to four 4K displays via two HDMI® ports, DisplayPort™ over USB-C® or other user-configurable ports, without any limitation on the combination used. Ultra-realistic 8K Visuals ASUS ExpertCenter PN52 delivers breathtaking 8K visuals at 30 frames per second via the configurable standard DisplayPort or DisplayPort over USB-C. Experience a level of detail that's 4X greater than 4K, or 16X that of traditional FHD output. USB Power Delivery Input ASUS ExpertCenter PN52 can draw power from any USB Power Delivery-enabled display or device, eliminating the need for a separate power adapter to create a neater, uncluttered workspace. Easy Upgrades An easy-access underside panel allows users replace and upgrade memory, storage and the wireless card. All that's required is a screwdriver. |
| Product Type | Barebone System |
| Number of Processors Supported | 1 |
| Processor Type | Ryzen 5 |
| Processor Model | 5600H |
| Processor Speed | 3.20 GHz |
| Maximum Turbo Speed | 4.10 GHz |
| 64-bit Processing | Yes |
| Chipset Manufacturer | AMD |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Supported Storage Drive Interfaces | Serial ATA III |
| Supported Storage Drive Types |
|
| Controller Type |
|
| Graphics Controller Model | Radeon Graphics |
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.2 |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 7 |
| Number of USB 3.2 Gen 1 Ports | 4 |
| Number of USB 3.2 Gen 2 Ports | 1 |
| USB Type-C (Front) | Yes |
| USB Type-C (Rear) | Yes |
| USB Type-C Detail | 1 x USB 3.2 Gen2 TypeC (w/ DP output & PowerDelivery input), 1 x USB 3.2 Gen1 Type C |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of SATA Interfaces | 1 |
| Operating System Supported |
|
| Maximum Power Supply Wattage | 120 W |
| Color Family | Black |
| Product Color | Eco Black |
| Form Factor | Mini PC |
| Height | 2.28" (58 mm) |
| Width | 4.72" (120 mm) |
| Depth | 5.12" (130 mm) |
| Package Contents |
|
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Condition | No |
| UPC | 0195553838030 |
