Barco Coronis Fusion MDCCâ€'6530 30" Class WQSXGA LED Monitor - 16:10 - Black, White
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | Barco |
| Manufacturer Part Number | K9602958 |
| Brand Name | Barco |
| Product Line | Coronis Fusion |
| Product Model | MDCCâ€'6530 |
| Product Name | Coronis Fusion MDCC-6530 Widescreen LED Monitor |
| Marketing Information | A brighter diagnosisCoronis Fusion, Barco's renowned multi-modality display for radiologists, now comes in a new, energy-efficient and lightweight design. Bright on so many levels, Coronis Fusion has been designed to help radiologists provide care with confidence. See more details quickly thanks to the high brightness, high contrast ratio and best-in-class image quality. What's more, the wide color gamut in combination with SteadyColor™ calibration technology helps you see even more colors and more details on the 30-inch screen. Smart workflowDesigned for your comfort and to boost productivity, Coronis Fusion comes with smart image-enhancing features and workflow tools. The display's wide viewing angle combined with the SoftGlow™ task and wall light help reduce eye strain. Thanks to SpotView, radiologists can further improve detection accuracy as well as reading productivity. Effortless quality & complianceLike all of Barco's medical display systems, Coronis Fusion comes with QAWeb Enterprise, a cloud-based technology for automated calibration, Quality Assurance and compliance to ensure maximum uptime of the display with no need for human intervention. A one-stop-shop solutionBarco medical display systems include exclusive display controllers that are validated with the latest workstations and with all major PACS applications. All components are under the full 5-year warranty (including the display backlight) for complete peace of mind. Ensuring diagnostic confidence with MDR Class IIaOur radiology displays are MDR-certified as Class IIa. Their product information has been reviewed and cleared by independent medical and technical experts, and is audited yearly. In other words, we ensure diagnostic confidence and peace of mind for our users. |
| Product Type | LED Monitor |
| Number of Screens | 1 |
| Screen Size Class | 30" |
| Viewable Screen Size | 30.4" |
| Screen Mode | WQSXGA |
| Panel Technology | In-plane Switching (IPS) Technology |
| Response Time | 18 ms |
| Response Time Details | 18ms (Tr+Tf)/2 |
| Aspect Ratio | 16:10 |
| Pixel Pitch | 0.19950 mm x 0.19950 mm |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Backlight Technology | LED |
| Features |
|
| Adjustable Stand | Yes |
| Stand Adjustments |
|
| Active Display Area (H x V) | 25.75" (654 mm) x 16.10" (409 mm) |
| Maximum Resolution | 3280 x 2048 |
| Contrast Ratio | 2,000:1 |
| Brightness | 1050 cd/m² |
| USB | Yes |
| DisplayPort | Yes |
| Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 4 |
| Number of USB 2.0 Upstream Ports | 1 |
| Number of USB 2.0 Downstream Ports | 3 |
| Number of DisplayPorts | 3 |
| Built-in Devices | USB Hub |
| Operating Temperature Range | 32°F (0°C) to 95°F (35°C) |
| Operating Humidity Range | 20% to 85% (Non-condensing) |
| Frequency |
|
| Maximum Power Consumption | 80 W |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Color Family | Dual Color |
| Color |
|
| Height | 18.82" (478 mm) |
| Width | 28.11" (714 mm) |
| Depth | 2.91" (74 mm) |
| Height with Stand | 24.57" (624 mm) |
| Width with Stand | 28.11" (714 mm) |
| Depth with Stand | 9.45" (240 mm) |
| Compressed Height with Stand | 20.63" (524 mm) |
| Extended Height with Stand | 24.57" (624 mm) |
| Weight (Approximate) | 28.88 lb (13100 g) |
| Weight with Stand (Approximate) | 39.02 lb (17700 g) |
| Package Contents |
|
| Application/Usage | Hospital |
| Environmental Compliance |
|
| Condition | No |
| Limited Warranty | 5 Year |
