Solidigm™ D7-P5520 Series (3.84TB, 2.5in PCIe 4.0 x4, 3D4, TLC) Generic Single Pack

Part No. SSDPF2KX038T11Z

by SOLIDIGM

Solidigm™ D7-P5520 Series (3.84TB, 2.5in PCIe 4.0 x4, 3D4, TLC) Generic Single Pack

Server Device Supported - 1 DWPD - 7168 TB TBW - 7100 MB/s Maximum Read Transfer Rate - 256-bit AES Encryption Standard - 5 Year Warranty - Bulk - 1

Part No. SSDPF2KX038T11Z

by SOLIDIGM

$2557.99
General Information
ManufacturerSOLIDIGM
Manufacturer Part NumberSSDPF2KX038T11Z
Brand NameSOLIDIGM
Product SeriesD7-P5520
Product NameD7-P5520 Solid State Drive
Marketing Information

The Industry's Most Advanced PCIe 4.0 Portfolio.1 Performance-Tuned for the Real World.

Our broadest and highest-performing family of TLC 3D NAND SSDs, Solidigm™ D7-P5520 and D7-P5620 drives (formerly Intel®), are the latest addition to the performance-optimized D7 series. These drives provide standard endurance and medium endurance, respectively, across an extended range of capacities and form factors. Building from multiple generations of PCIe 4.0 and deep industry insight, this is the industry's most advanced PCIe 4.0 portfolio with performance tuned for real-world applications. They efficiently accelerate compute and storage workloads in cloud and enterprise across a breadth of 1U and 2U server configurations. Designed and tested with zero tolerance for data errors2 and consistently durable performance,3 they can be deployed with the utmost confidence.

Product series highlights

Compared to the previous generation of PCIe 4.0 products, performance has been significantly boosted across the board, enabling workload acceleration in mixed and read-intensive applications.

Packaged Quantity1
Package TypeBulk
Product TypeSolid State Drive
Technical Information
Storage Capacity3.84 TB
Encryption Standard256-bit AES
Drive Performance
Maximum Read Transfer Rate7100 MB/s
Maximum Write Transfer Rate4200 MB/s
Random 4KB Read1100000IOPS
Random 4KB Write220000IOPS
Endurance (DWPD)1
Endurance (TBW)7168 TB
Endurance TypeRead Intensive
Maximum Sequential Read6.54 GB/s
Maximum Sequential Write3.52 GB/s
Mean Time Between Failures (MTBF)228.2 Year
Network & Communication
Wireless LANNo
Interfaces/Ports
Drive InterfaceU.2
Drive Interface StandardPCI Express NVMe 4.0 x4
Physical Characteristics
Drive TypeInternal
Form Factor2.5"
Height0.59" (15 mm)
Weight (Approximate)5.82 oz (165 g)
Miscellaneous
Device SupportedServer
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
ConditionNo
UPC840307303226
Warranty
Limited Warranty5 Year
