FSP Group U580-BA Computer Case

Ultra Tower - Black - Tempered Glass, SPCC - 3 x Bay - 7 x 120mm Fan(s) Installed - ATX, Mini ITX, Micro ATX Motherboard Supported - 10 x Fan(s) Supported - 1 x Internal 3.5" Bay - 2 x Internal 2.5" Bay - 9x Slot(s) - 3 x USB(s) - 2 x USB 3.0, 1 x USB Type C - Fan/Liquid Cooler

Part No. POC0000304

by FSP Group USA Corp

$153.99

Specifications

General Information

Manufacturer	FSP Group USA Corp
Manufacturer Part Number	POC0000304
Brand Name	FSP Group
Product Model	U580-BA
Product Name	U580-BA Computer Case
Marketing Information	Innovative Design Meets Crystal Clarity The U580 Three-Glass PC Case redefines showcase aesthetics with tempered glass panels on the front, and side. Its sleek, modern design offers a panoramic view of your build while supporting high-performance components and optimized airflow. The side and bottom come pre-installed with six 120mm PWM ARGB fans, while the rear features a 120mm ARGB fan. 160mm tall CPU COOLER Supports up to 160mm CPU cooler. 415mm-long GRAPHICS CARDS x 2 It supports dual high-end graphics cards. 360mm-long RADIATOR Supports up to 360mm radiators on side, top and bottom panels. Clean Builds, Cool Performance Compatible with ATX (BTF), M-ATX, and Mini-ITX motherboards, the U580 features built-in cable routing for clean back-connect setups. With seven pre-installed 120mm ARGB fans, it delivers both striking visuals and high-efficiency cooling. Dual-chamber, Organized Space Designed with a dual-chamber layout, the U580 keeps the PSU, hard drives, and cables neatly tucked away, delivering a clean and clutter-free build. Combining refined aesthetics with high-performance potential, it features tempered glass panels on three sides, showcasing your components in style. STORAGE SSD x 2HDD x 1 USB PORT Type-C / USB3.0 x 2 PSU 240mm PSU
Product Type	Computer Case

Technical Information

Motherboard Supported	ATX Mini ITX Micro ATX
Number of Fans Supported	10
Fan Supported Details	Fan Including(Pre-installed): Front: Side:120mm reverse PWM ARGB x 3 with PWM controller Bottom: 120mm reverse PWM ARGB x 3 Rear: 120mm ARGB x 1 Fan&Water Cooler Support: Side:120mm x 3 or 140mm x 2 or 360mm Radiator Top: 120mm x 3 or 360mm Radiator Bottom: 120mm x 3 or 240mm Radiator Rear: 120mm x 1
Number of Fans Installed	7
Fan Size Supported	4.72" (120 mm) 5.51" (140 mm)
Installed Fan Size	4.72" (120 mm)
Installed Fan Size Details	7 x 120mm
Features	Dual Chamber ARGB Fan
Window Panel	Yes
Window Panel Location	Front Side Panel

Bays

Number of Internal 3.5" Bays	1
Number of Internal 2.5" Bays	2
Number of Total Expansion Bays	3

I/O Expansions

Total Number of Expansion Slots	9

Interfaces/Ports

Total Number of USB Ports	3
USB Port Details	2 x USB 3.0 1 x USB Type C

Physical Characteristics

Color Family	Black
Product Color	Black
Product Material	Tempered Glass SPCC
Cooler Type	Fan/Liquid Cooler
Form Factor	Ultra Tower
Maximum CPU Cooler Height	6.30" (160 mm)
Maximum PSU Length	9.45" (240 mm)
Maximum GPU Length	16.34" (415 mm)
Height	17.83" (453 mm)
Width	11.22" (285 mm)
Depth	16.77" (426 mm)
Weight (Approximate)	18.36 lb (8330 g)
