StarTech.com 4 Port PCI Express PCIe Serial Combo Card - 2 x RS232 2 x RS422 / RS485
Add two RS232, and two RS422/485 serial ports to your PC through a PCI-Express expansion slot - pcie rs485 - pci express rs485 - pcie rs485 - pci express rs422 - pcie rs422
$215.99
In Stock Availability
- All Locations: (435+)
- Other_SY (435+)
General Information
| Manufacturer | StarTech.com |
| Manufacturer Part Number | PEX4S232485 |
| Brand Name | StarTech.com |
| Product Name | 4 Port PCI Express PCIe Serial Combo Card - 2 x RS232 2 x RS422 / RS485 |
| Marketing Information | The PEX4S232485 4 Port PCI Express PCIe Serial Combo Card - 2 x RS232 2 x RS422 / RS485 lets you add two RS232, and two RS422/485 serial ports to your PC through a PCI-Express expansion slot. This PCI express serial card is a single card solution that is compatible with nearly any serial communication protocol, supporting RS-232, RS-422, RS-485 2-wire or RS-485 4-wire operating modes. A flexible solution for adding serial ports to full-sized, or small form factor systems, the 4-port serial card includes both low and full profile brackets while the included breakout cable helps to avoid cluttered connections. Backed by a StarTech.com lifetime warranty and free lifetime technical support. More from the Manufacturer |
| Packaged Quantity | 1 Each |
| Product Type | Multiport Serial Adapter |
Technical Information
| Host Interface | PCI Express x1 |
| Maximum Data Transfer Rate | 3.59 Mbit/s |
| Platform Supported | PC |
Interfaces/Ports
| Ports Expandability | 4 x DB-9 RS-232/422/485 - Serial, Via Cable |
Physical Characteristics
| Form Factor | Plug-in Card |
| Height | 2.70" (68.58 mm) |
| Width | 0.60" (15.24 mm) |
| Weight (Approximate) | 2.40 oz (68.04 g) |
Miscellaneous
| Package Contents |
|
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance |
|
| End of Life Manual Availability | Yes |
| EU RoHS Declaration URL | https://media.startech.com/cms/pdfs/pex4s232485_rohs.pdf |
| REACH Declaration URL | https://media.startech.com/cms/pdfs/pex4s232485_rohs.pdf |
| REACH free of SVHC | Yes |
| WEEE Statement | https://media.startech.com/cms/pdfs/pex4s232485_weee.pdf |
| Condition | No |
| UPC | 0065030849357 |
Warranty
| Limited Warranty | Lifetime |
