Black Box KVM Switchbox

50 Hz, 60 Hz - 18 x Network (RJ-45) - 1U - Rack-mountable

Part No. ACXC16

by Black Box Corporation

$8435.99

Specifications
Options & Accessories (3)

General Information

Manufacturer	Black Box Corporation
Manufacturer Part Number	ACXC16
Brand Name	Black Box
Product Name	KVM Switchbox
Marketing Information	Quick Facts Use the cost-efficient DKM FX Compact switches to establish connections from consoles (monitor, keyboard, mouse, and other peripheral devices) to various sources, such as computers and CPUs. RJ-45 CATx ports can be input or output. Chassis is 1U for easy mounting in server cabinet and racks. Further Details Use with DKM Modular and Compact Extenders (ACX1MT and ACX1MR series, and ACX1T and ACX1R series) to extend video, KVM, and USB 2.0 signals. Can also be run as a video matrix switch. Uses CATx cabling for extension. DKM FX Compact HD Video and Peripheral Matrix Switches serve as repeaters, which mean they can be a maximum distance of 460 feet (140 m) from consoles or sources. Redundant power supplies included. Optional software bundles for external control, SYSLOG/SNMP, seamless cascading, etc. - one-time license purchase is good for the life of the switch.
Product Type	KVM Switchbox

Technical Information

Maximum Operating Distance	460 ft (140208 mm)

Interfaces/Ports

Network (RJ-45)	Yes
Number of Network (RJ-45) Ports	18

Power Description

Input Current	2 A
Input Voltage Range	90-240 VAC
Frequency	50 Hz 60 Hz

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	1U

Miscellaneous

Certifications & Standards	CE
Environmentally Friendly	Yes
Country of Origin	Germany
Condition	No
UPC	822088002772

Warranty

Limited Warranty	2 Year
