• Secure access to IT equipment with RS-232 and USB console ports
• Access devices via Telnet/SSH or a Web browser-based console client without any proprietary software.
• Leverage the command line interface of most IT equipment for reconfiguring, rebooting and reloading firmware from a single point of contact.
• Connect in-band with dual Gigabit Ethernet or dual SFPs and through out-of-band connections including dial-up and cellular connectivity options.
• Modular design to deploy what you need at each location, up to 48 ports: RJ-45 serial, Ethernet, or serial USB.

More from the Manufacturer

• Remote Monitoring
• Remote Management

• In-Band (10/100/1000 Base - Ethernet) - Dual Ethernet ports with bonding
• Out-of-Band (Local terminal, Internal Modem or USB Modem)

• Secure Shell (SSH v1, v2, Public Key)
• Secure Sockets Layer (SSL v3, TLS v1)
• Packet filtering (firewall)
• Per port user permissions
• Configurable user rights and custom groups
• Remote authentication: LDAP, RADIUS, Kerberos, TACACS+, Active Directory, NIS
• Local username/password
• FIPS 140-2 compliant cryptography (Certificate #1878)

• Software reversible device port pins
• Telnet/SSH to SLC command line
• Telnet/SSH/RAW-TCP direct to IP address and port number
• Web Telnet/SSH
• Multiple concurrent Telnet/SSH sessions
• Simultaneous access on the same port
• No inadvertent "breaks" - Sun break-safe
• Customizable multi-level user menus
• USB port modem access
• Automatic port-initiated connections to network host or neighboring port
• Enable terminal login on any device port
• SD card and USB

• Port buffering - 256 KB per port
• Port logging to local files, syslog, USB thumb drive, SD card, and NFS share
• NFS files (simultaneous)
• System event logs
• Console event notification via email
• Event string recognition (RegExp)

• Front panel keypad and LCD display for network setup
• Quick setup and configuration web interface (SSL)
• CLI setup script
• Command line interface (Telnet, SSH, Web Telnet/SSH or direct serial)
• SNMP (MIB II) compatible-v1, v2, v3, custom MIB's
• Integrated power management support-Lantronix SLP® and Server Technology PDU
• Integrated support for Sensorsoft devices
• Diagnostics and port status counters
  • Performance monitoring utility
  • Packet generation utility
  • Network trace utility
  • Configuration audit log
• Active user list display, port monitoring and timeout
• Local subnet search for other SLC's
• Maximum of 352 concurrent users and maximum 10 users per device port at 9600 baud rate (typical)

• DHCP and BOOTP for dynamic IP address assignment
• NTP for time synchronization
• FTP, TFTP, SFTP, SCP client for file transfers
• DNS for text-to-IP address name resolution
• SSH, SSL, Telnet and UDP, PPP with PAP/CHAP, NFS and CIFS for connections in and out of the SLC
• IPsec/VPN
• RIP and RIPv2

• Network: Dual 10/100/1000 Base-T RJ45 Ethernet
• Devices: 8, 16, 32, 48 Serial, 300 to 230400 bps
• Console: RS-232 (RJ45), 300 to 230400 bps
• USB 2.0 High Speed, Full Speed, Low Speed
• SD card slot: SD and SDHC
