AddOn 10/100/1000Base-TX(RJ-45) to Open SFP Port Industrial POE Media Converter
1 x Network (RJ-45) - 1x PoE+ (RJ-45) Ports - Multi-mode, Single-mode - Gigabit Ethernet - 10/100/1000Base-TX - 1 Gbit/s - 1 x Expansion Slots - SFP - 1 x SFP Slots - PoE+ - Rail-mountable, Wall Mountable
$744.99
On back-order, will ship once in-stock
- All Locations: (0+)
General Information
| Manufacturer | AddOn |
| Manufacturer Part Number | ADD-IGMC-SFP-POE+ |
| Brand Name | AddOn |
| Product Name | 10/100/1000Base-TX(RJ-45) to Open SFP Port Industrial POE Media Converter |
| Marketing Information | This is an industrial POE media converter that converts a 10/100/1000Base-TX(RJ-45) to 1000Base-X via an open SFP port connector. The open SFP port allows users to customize between the SX, LX, or BX connections. This media converter provides a cost effective conversion from 10/100/1000Base-TX(RJ-45) to 1000Base-X, while extending the network reach beyond the 100m reach limitation of copper. This industrial grade product includes a terminal block and does not come with a power plug. This PoE+ media converter is a Power Sourcing Equipment (PSE), which combines data transferred over a fiber optic link with 48V (or other voltage) power supply, 30 watts max, providing power to IEEE802.3at powered device (PD) over CAT5 and up UTP cable (cable length up to 100 meters / 330 feet). It complies with the IEEE802.3at standard. The converter includes a single port PSE controller, which offers PD signature sensing and power monitoring features. Other features include over-current protection and LFP function. The LFP (Link Fault Pass-through) allows the media converter to monitor both the fiber and copper RX port for loss of signal. In case of a loss of RX signal on one media port, the converter will automatically disable the TX signal to the other media port, thus passing through the link fault. Our media converters and network interface cards are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs. |
| Packaged Quantity | 1 |
| Product Type | Transceiver/Media Converter |
Interfaces/Ports
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| DVI | No |
| USB | No |
| Management Port | No |
| Number of PoE+ (RJ-45) Ports | 1 |
| PoE Port Type | PSE |
| Number of Network (RJ-45) Ports | 1 |
Media & Performance
| Media Type Supported |
|
| Fiber Mode Supported |
|
| Maximum Data Transfer Rate | 1 Gbit/s |
I/O Expansions
| Total Number of Expansion Slots | 1 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 1 |
Network & Communication
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-TX |
Power Description
| Power Source | PoE+ |
| Power Consumption | 30 W |
| Plug/Connector Type | Terminal Block |
Physical Characteristics
| Form Factor |
|
| Height | 5.50" (139.70 mm) |
| Width | 4.50" (114.30 mm) |
| Depth | 1.75" (44.45 mm) |
| Weight (Approximate) | 8 oz (226.80 g) |
Miscellaneous
| Application/Usage | Industrial |
| Additional Information | |
| Compatibility | |
| Certifications & Standards | 802.3at |
| Country of Origin | China |
| TAA Compliant | No |
| Condition | No |
| UPC | 821455495445 |
Warranty
| Limited Warranty | 3 Year |
