Juniper QFX5110-48S Ethernet Switch
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | Juniper Networks, Inc |
| Manufacturer Part Number | QFX5110-48S-DC-AFO |
| Brand Name | Juniper |
| Product Series | QFX |
| Product Model | QFX5110-48S |
| Product Name | QFX5110-48S Ethernet Switch |
| Marketing Information | QFX5110 access and aggregation switches deliver low latency, rich Layer 2 and Layer 3 features, VXLAN overlay deployments, and 100GbE uplinks, making it the industry's most nimble line of switches. Featuring L3 gateway capabilities for bridging between virtualized and bare-metal servers, the QFX5110 is designed for extremely agile data centers that demand support for overlay/underlay network architectures. The highdensity 10GbE, 40GbE, and 100GbE ports also make the QFX5110 ideally suited for use in spine and leaf topologies. Product Description Data centers are rapidly adopting cloud services, whether completely off-premise models or hybrid models with critical services offered through on-premise private clouds. The tremendous growth of off-premise cloud services, coupled with the widespread adoption of overlay technologies, has created a need for highly agile switching platforms that can satisfy the demands of these evolving data centers. The high-performance Juniper Networks® QFX5110 line of Ethernet switches fit the bill, providing the foundation for dynamic data centers. As a critical enabler for IT transformation, the data center network supports cloud and SDN adoption, network virtualization, integrated/scale-out storage, and the rapid deployment and delivery of mission-critical applications that significantly increase east-west traffic within the data center. Furthermore, increasing demand for 100GbE spine ports is driving the need for 100GbE uplinks for all server access speeds, including 10GbE and 40GbE. The QFX5110 includes 100GbE uplinks, enabling it to support a diverse set of switching architectures, including fabric, Layer 3, and spine-and-leaf deployments, enabling users to easily adapt as requirements change over time. Architecture and Key Components The QFX5110 switches include 10GbE (fiber) and 40GbE or 100GbE fixed-configuration options with rich Layer 2, Layer 3, and MPLS features. The QFX5110 switches run the same reliable, high-performance Juniper Networks Junos® operating system that is used by the Juniper Networks QFX5100 family of products, EX Series Ethernet Switches, Juniper Networks routers, and Juniper Networks SRX Series Services Gateways, ensuring a consistent implementation and operation of control plane features across the entire Juniper infrastructure. QFX5110 Switch Models The QFX5110 switches are compact, 1 U platforms that provide wire-speed packet performance, very low latency, and a rich set of Junos OS features. In addition to a highthroughput Packet Forwarding Engine (PFE), the performance of the QFX5110 control plane is further enhanced with a powerful 1.8 GHz quad-core Intel CPU with 16 GB of memory and 64 GB SSD storage. Two QFX5110 switch models are available:
|
| Product Type | Ethernet Switch |
| Modular | Yes |
| Port/Expansion Slot Details |
|
| Media Type Supported | Optical Fiber |
| Ethernet Technology |
|
| Network Technology |
|
| Total Number of Expansion Slots | 52.0 |
| Expansion Slot Type |
|
| Number of SFP+ Slots | 48 |
| Layer Supported | 3 |
| Manageable | Yes |
| Power Source | Power Supply |
| Redundant Power Supply Supported | Yes |
| Power Consumption | 300 W |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.72" (43.70 mm) |
| Width | 17.36" (440.90 mm) |
| Depth | 20.48" (520.20 mm) |
| Weight (Approximate) | 22.99 lb (10430 g) |
| Environmentally Friendly | Yes |
| Environmental Compliance |
|
| Condition | No |
| UPC | 0832938071483 |
| Limited Warranty | 1 Year |
