StarTech.com Multi-Input HDBaseT Extender Kit with Built-In Switch and Video Scaler - DisplayPort HDMI and VGA Over CAT6 or CAT5e

Part No. ST121HDBTSC

by StarTech.com

StarTech.com Multi-Input HDBaseT Extender Kit with Built-In Switch and Video Scaler - DisplayPort HDMI and VGA Over CAT6 or CAT5e

Connect four video sources to a remote HDMI display over CAT5e/CAT6 cabling and easily scale and switch between HDMI DP or VGA video sources - HDBaseT extender kit - Video Scaler - DisplayPort extender - HDBaseT HDMI extender - HDMI and VGA over CAT6

Part No. ST121HDBTSC

by StarTech.com

$895.99
General Information
ManufacturerStarTech.com
Manufacturer Part NumberST121HDBTSC
Brand NameStarTech.com
Product NameMulti-Input HDBaseT Extender Kit with Built-In Switch and Video Scaler
Marketing Information

This multi-input HDBaseT™ extender kit extends your A/V signals to a remote location up to 230 ft. (70 m) away. It features a built-in switch and scaler, so you can choose which video source is output from four independent video sources (2 x HDMI, 1 x VGA and 1 x DisplayPort).

Seamless Integration and Operation

The HDBaseT extender's built-in converter switch lets you connect two HDMI sources, a VGA source, and a DP source to the same remote and local HDMI display. You don't need adapters or scalers, or a video switch.

Along with manually switching your video source with easy-to-use buttons, the video extender ensures hassle-free operation with two auto-switching modes: auto-detect switching, which detects and selects a newly connected device, and priority selection, which lets you choose which port is activated by default, for automatic switching.

Built-In Video Scaling

This HDBaseT extender features a built-in scaler that scales the image to 1080p, so you can rest assured your HDMI display will intuitively work with any source that's connected through it. Scaling is easy to do, with an intuitive OSD that's accessible using buttons on the remote receiver. Newer HDMI displays no longer support legacy resolution video signals. Without support for these common VGA resolutions, your source may not work with your new HDMI display.

High-Definition 1080p Video at 230 Feet (70 Meters)

The extender kit maintains your HD picture quality, even at 230 ft. (70 m) away from your video source, ensuring you can provide the best possible viewing experience.

The ST121HDBTSC is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Packaged Quantity1 Kit
Product TypeVideo Extender Transmitter/Receiver
Technical Information
Connectivity TechnologyWired
Number of Input Devices Supported4
Number of Output Devices Supported1
Maximum Operating Distance229.66 ft (70000 mm)
Video
Graphics ModesWUXGA
Maximum Video Resolution1920 x 1200
Interfaces/Ports
Network (RJ-45)Yes
HDMI InYes
HDMI OutYes
VGA InYes
DisplayPortYes
Number of Network (RJ-45) Ports2
Number of HDMI Inputs2
Number of HDMI Outputs2
Number of VGA Inputs1
Media & Performance
Media Type SupportedTwisted Pair
Twisted Pair Cable StandardCategory 6
Physical Characteristics
Color FamilyBlack
Product ColorBlack
Transmitter Height2.60" (66.04 mm)
Transmitter Width2.40" (60.96 mm)
Transmitter Depth4.20" (106.68 mm)
Receiver Height2.60" (66.04 mm)
Receiver Width2.40" (60.96 mm)
Receiver Depth4.20" (106.68 mm)
Form FactorDesktop
Transmitter Weight (Approximate)4.41 lb (2000 g)
Receiver Weight (Approximate)4.41 lb (2000 g)
Miscellaneous
Package Contents
  • 1 x HDBaseT Transmitter
  • 1 x HDBaseT Scaler Receiver
  • 1 x Remote Control
  • 1 x RJ-11 to RS-232 Adapter
  • 1 x CAT5 Cable
  • 1 x RJ-11 Cable
  • 2 x Sets of Mounting Brackets
  • 1 x Universal Power Adapter (NA/JP, EU, UK, ANZ)
  • 1 x IR Blaster
  • 1 x IR Receiver
  • 2 x Sets of Rubber Feet
  • 1 x Quick-Start Guide
Country of OriginTaiwan
TAA CompliantYes
Environmentally FriendlyYes
Environmental Compliance
  • Restriction of Hazardous Substances (RoHS)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
  • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
ConditionNo
UPC065030879200
Warranty
Limited Warranty2 Year
