Digi Connect EZ 4i - Serial Server, 4-port, Industrial-rated, with Wi-Fi and Accessories

Part No. EZ04-IA00-EXT

by Digi International

$1471.99

In Stock Availability

  • All Locations: (1+)
  • Guelph, ON (1+)

Digi Connect EZ 4i - Serial Server, 4-port, Industrial-rated, with Wi-Fi and Accessories

512 MB - Twisted Pair - 2 x Network (RJ-45) - 4 x Serial Port - 10/100/1000Base-T - Gigabit Ethernet - IEEE 802.11a/b/g/n/ac - Wireless LAN - ISM Band ISM Band - UNII Band UNII Band - DIN Rail Mountable

Part No. EZ04-IA00-EXT

by Digi International

$1471.99

In Stock Availability

  • All Locations: (1+)
  • Guelph, ON (1+)

General Information
ManufacturerDigi International
Manufacturer Part NumberEZ04-IA00-EXT
Brand NameDigi
Product LineConnect EZ 4i
Product NameConnect EZ 4i - Serial Server, 4-port, Industrial-rated, with Wi-Fi and Accessories
Packaged Quantity1 Pack
Product TypeDevice Server
Technical Information
Connectivity TechnologyWired
Data Link Protocols
  • HTTP
  • HTTPS
Memory
Standard Memory512 MB
Media & Performance
Media Type SupportedTwisted Pair
Wireless Specifications
Wireless LANYes
Wireless LAN StandardIEEE 802.11a/b/g/n/ac
ISM BandYes
UNII BandYes
Network BandDual Band
Network & Communication
Ethernet TechnologyGigabit Ethernet
Network Standard10/100/1000Base-T
Interfaces/Ports
Network (RJ-45)Yes
Serial PortYes
Total Number of Network Ports2
Number of Network (RJ-45) Ports2
Number of Serial Ports4
Environmental Conditions
Minimum Operating Temperature-31°F (-35°C)
Maximum Operating Temperature165.2°F (74°C)
Power Description
Input Voltage
  • 9 V DC
  • 30 V DC
Input Voltage Range9 V DC to 30 V DC
Power Consumption4.50 W
Input Current1.50 A
Physical Characteristics
Form FactorDIN Rail Mountable
Height1.38" (35 mm)
Width5.28" (134 mm)
Depth7.56" (192 mm)
Miscellaneous
Package Contents
  • Connect EZ 4i - Serial Server, 4-port, Industrial-rated, with Wi-Fi and Accessories
  • 2-position Rewireable Plug with Securing Screws
  • Antenna - 2.4 and 5 GHz
  • Power Supply - 12 V, 2.5 A
  • DIN Rail Clip
Certifications & Standards
  • IEC62368-1
  • CB, EN62311
  • Industrial certification: Class 1, Division 2
  • IEC 60068-2-64
  • 60068-2-27
  • CE
  • RED
  • FCC Part 15
  • Subpart B; ICES-003; AU/NZS CISPR32
Environmental Compliance
  • Restriction of Hazardous Substances (RoHS) 3
  • Restriction of Hazardous Substances (RoHS)
ConditionNo
Warranty
Limited Warranty5 Year
Additional Warranty Information

Technical support: 1-year LifeCycle Assurance with 24x7 Expert Support included

connector adapters (5)
Digi 76000699 Network Adapter

Part No. 76000699

Digi 76000699 Network Adapter - 1 x 25-pin DB-25 Serial Female - 1 x RJ-45 Network - 4

DIGI ONE,PRTRV TS II 4 PK DB25F CONSOLE ADP

$69.99

On back-order, will ship once in-stock

  • All Locations: (0+)

Digi Serial Adapter DCE

Part No. 76000700

Digi Serial Adapter DCE - 1 x 25-pin DB-25 Serial Male - 1 x RJ-45 - 4

Digi One, PortServer TS, II 4 pack DB-25M Modem Adapter (10 pin)

$83.99

In Stock Availability

  • All Locations: (66+)
  • Other_SY (66+)

Digi TS Console Adapter

Part No. 76000698

Digi TS Console Adapter - 1 x 25-pin DB-25 Male - 1 x RJ-45 Female - 4

Digi One, PortServer TS, II 4 pack DB-25M Console Adapter (10 pin)

$59.99

In Stock Availability

  • All Locations: (19+)
  • Other_SY (19+)

Digi Serial Console Adapter

Part No. 76000697

Digi Serial Console Adapter - 1 x 9-pin DB-9 Male - 1 x RJ-45 - 4

DIGI ONE PRTRV TS II 4 PK DB 9F CONSOLE ADP

$71.99

In Stock Availability

  • All Locations: (12+)
  • Other_SY (12+)

Digi TS DB-9M to RJ-45 Modem Adapter

Part No. 76000701

Digi TS DB-9M to RJ-45 Modem Adapter - 1 x 9-pin DB-9 Male - 1 x RJ-45 - 4

DIGI ONE PRTRV TS, II 4 PK DB 9M MODEM ADP

$73.99

In Stock Availability

  • All Locations: (40+)
  • Other_SY (40+)

connector cables (7)
Digi Etherlite RJ45 8 pin Female to TS RJ45 10 pin Male 6" cable package of 16

Part No. ELF-TSM-CBL-16

Digi Etherlite RJ45 8 pin Female to TS RJ45 10 pin Male 6" cable package of 16 - 6" (152.40 mm) RJ-45 Network Cable for Server, Barcode Scanner - First End: 1 x 8-pin RJ-45 Network - Female - Second End: 1 x 10-pin RJ-45 Network - Male - Black - 16

Network Cable - Female Left Gender - Male Right Gender - RJ45 Right Connector -RJ45 Left Connector - 6Inch Length

$732.99

On back-order, will ship once in-stock

  • All Locations: (0+)

Digi RJ45 to DB25 Cable

Part No. 76000195

Digi RJ45 to DB25 Cable - RJ-45 Male - DB-25 Male - 1.22m

DIGI - SERIAL CABLE ( DTE ) - RJ-45 (M) - DB-25 (M) - 4 FT

$47.99

In Stock Availability

  • All Locations: (2+)
  • Guelph, ON (2+)

Digi Crossover DCE Cable

Part No. 76000238

Digi Crossover DCE Cable - RJ-45 Male - DB-25 Male - 1.22m

SERIAL CABLE - DB-25 - MALE - RJ-45 - MALE - 4 FT

$46.99

In Stock Availability

  • All Locations: (20+)
  • Calgary, AB (1+)
  • Other_SY (19+)

Digi Serial Straight-through Cable Adapter

Part No. 76000199

Digi Serial Straight-through Cable Adapter - RJ-45 Male, DB-25 Female - 1.22m

DIGI INTERNATIONAL - DIGI - SERIAL CABLE ( DTE ) - RJ-45 (M) - DB-25 (F) - 4 FT

$51.99

On back-order, will ship once in-stock

  • All Locations: (0+)

Digi DCE Cable

Part No. 76000201

Digi DCE Cable - RJ-45 Male - DB-9 Female - 1.22m

NETWORK CABLE ( DTE ) - RJ-45 (M) - DB-9 (F)

$54.99

In Stock Availability

  • All Locations: (18+)
  • Guelph, ON (3+)
  • Other_SY (15+)

Digi Crossover DCE Cable

Part No. 76000264

Digi Crossover DCE Cable - RJ-45 Male - DB-9 Male - 1.22m

DIGI INTERNATIONAL - DIGI - CROSSOVER CABLE ( DCE ) - RJ-45 (M) - DB-9 (M) - 4 FT

$50.99

On back-order, will ship once in-stock

  • All Locations: (0+)

Digi Serial Cable

Part No. 76000723

Digi Serial Cable - RJ-45 - Bare Wire - 121.92cm

Network Cable - Male Right Gender - RJ45 Right Connector - Bare wire Left Connector - 48Inch Length

$42.99

On back-order, will ship once in-stock

  • All Locations: (0+)

mounting kits (2)
Digi Din Rail Mount for Router

Part No. 76002095

Digi Din Rail Mount for Router

DIGI DIN RAIL CLIP SCREWS TO SUIT IX10 IX20

$6.99

On back-order, will ship once in-stock

  • All Locations: (0+)

Digi Mounting Bracket for DIN Rail, Router

Part No. 76002093

Digi Mounting Bracket for DIN Rail, Router

MOUNTING BRACKET DIN RAIL CLIP SCREWS SMA ADAPTERS AND PACKAGING FITS IX14 AND IX20

$56.99

On back-order, will ship once in-stock

  • All Locations: (0+)
