ATEN 2-Console 8-Port Multi-Interface (DisplayPort, HDMI, DVI, VGA) Cat 5 KVM Switch
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | ATEN Technology, Inc |
| Manufacturer Part Number | KH2508A-PB |
| Brand Name | ATEN |
| Product Model | KH2508A |
| Product Name | 2-Console 8-Port Multi-Interface (DisplayPort, HDMI, DVI, VGA) Cat 5 KVM Switch |
| Marketing Information | The KH2508A KVM switch is a control unit that allows IT administrators to access and control multiple computers from two PS/2 or USB KVM consoles (two bus). Operators working at up to two consoles can independently and simultaneously take control of up to 8 computers. By daisy chaining up to 15 additional switches, as many as 128 computers can be controlled from the original KVM consoles. This switch has been designed with unique and powerful features that enable administrators to manage their entire server room and data center devices easily and conveniently. For example, the advanced Adapter ID feature stores the Adapter Cable's configuration information - such as its ID, port name, OS, keyboard language, etc. This feature allows administrators to relocate servers to different ports without having to reconfigure the adapters . Another advantage found in these switches is Full HD video quality - extending the distance to the servers to up to 30 m at a resolution of 1920 x 1200. In addition, the switches are compatible with ATEN KVM adapter cable. This allows flexible interface combinations (PS/2, USB with VGA, DVI, HDMI and DisplayPort video interface, Sun and serial) to control all computer types. A KH2508A installation provides one of the best, and most economical, solutions ATEN offers to the SMB market. There is no better way to save time, space, and money than with a KH2508A KVM switch. |
| Packaged Quantity | 1 |
| Product Type | KVM Switchbox |
| Connectivity Technology | Wired |
| Number of Computers Supported | 8 |
| Maximum Operating Distance | 164.04 ft (50000 mm) |
| Features | LED Indicator |
| Graphic Mode | Full HD |
| Maximum Video Resolution | 1920 x 1200 |
| Network (RJ-45) | Yes |
| USB | Yes |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 8 |
| Number of USB Ports | 4 |
| Number of VGA Ports | 2 |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Input Current | 1 A |
| Input Voltage Range | 100-240 VAC |
| Frequency |
|
| Height | 1.73" (44 mm) |
| Width | 6.13" (155.80 mm) |
| Length | 17.21" (437.20 mm) |
| Weight (Approximate) | 6.19 lb (2810 g) |
| Package Contents |
|
| Compatibility | Cat 5 KVM Switches: KH2508A, KH2516A KVM Extenders: CE350, CE700A KVM over IP Switches: CN800, CN8000A LCD KVM Switches / Consoles: CL3108, CL3116 Rack KVM Switches: CS1716A Daisy Chain Cables: 2L-2700, 2L-2701, 2L-2703, 2L-2705, 2L-2715 |
| Condition | No |
| Limited Warranty | 3 Year |
