Transition Networks S2220-1040 Transceiver/Media Converter
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | S2220-1040-SA |
| Brand Name | Transition Networks |
| Product Line | ION |
| Product Series | S2220 |
| Product Model | S2220-1040 |
| Product Name | S2220-1040 Transceiver/Media Converter |
| Marketing Information | Stand-alone Fast Ethernet Remotely Managed NID 10/100/1000Base-T to 100Base-FX with OAM/IP-Based Management The ION S2220 is a stand-alone managed Network Interface Device (NID) that provides an interface between 10/100/1000Base-T ports and 100Base-FX ports, allowing users to manage their links while integrating fiber optic cabling into 10/100/1000 copper environments. As a remotely managed device, the S2220 can be managed individually via an IP address or it can be managed in-band, over the fiber when linked to a C2220 card installed in a managed ION chassis. With advanced features like IEEE 802.3ah Link OAM, VLAN, QoS, SSH/SSL, jumbo frame support, and bandwidth allocation, the S2220 offers a variety of methods for the secure delivery of Ethernet services in business and mobile backhaul applications. |
| Product Type | Transceiver/Media Converter |
| Total Number of Ports | 1 |
| Network (RJ-45) | Yes |
| USB | Yes |
| Management Port | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Media Type Supported |
|
| Maximum Data Transfer Rate | 1000 Mbit/s |
| Maximum Distance Supported | 0.10 km (0.06 Mile) |
| Total Number of Expansion Slots | 1 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 1 |
| Ethernet Technology |
|
| Network Technology |
|
| Power Source | Power Supply |
| Input Voltage |
|
| Form Factor |
|
| Height | 1" (25.40 mm) |
| Width | 3.25" (82.55 mm) |
| Depth | 6.50" (165.10 mm) |
| Weight (Approximate) | 2 lb (907.18 g) |
| Package Contents | |
| Application/Usage |
|
| Additional Information | 10/100/1000Base-T (RJ-45) [100 m] to 100Base-X SFP Slot (empty) |
| Certifications & Standards | EN55022 class A, EN55024, UL60950, CE Mark |
| Environmentally Friendly | Yes |
| Environmental Compliance |
|
| TAA Compliant | Yes |
| NDAA Compliant | Yes |
| Condition | No |
| UPC | 648177049936 |
| Limited Warranty | Lifetime |
