CradlePoint Wi-Fi 6 IEEE 802.11ax Ethernet Wireless Router

Part No. BF01-03001855-GN

by CradlePoint, Inc

CradlePoint Wi-Fi 6 IEEE 802.11ax Ethernet Wireless Router

Dual Band - 2.40 GHz ISM Band - 5 GHz UNII Band - 221.75 MB/s Wireless Speed - 4 x Network Port - 1 x Broadband Port - USB - 10 Gigabit Ethernet - VPN Supported - Desktop, Wall Mountable

Part No. BF01-03001855-GN

by CradlePoint, Inc

$4805.99
General Information
ManufacturerERICSSON
Manufacturer Part NumberBF01-03001855-GN
Brand NameCradlePoint
Product SeriesE300
Product NameE300 Wireless Router
Marketing Information

The Cradlepoint NetCloud Enterprise Branch Service with E300 Series Router is ideally suited for providing 4G and 5G cellular connectivity, agile VPN security, and cellular optimized SD-WAN to pop-up temporary locations, branches, stores, and clinics. The all-in-one form factor includes full-featured routing, security, and Wi-Fi, making it easy to connect offices and sites to the Internet and critical applications without the need for extra hardware or complicated configurations. And the embedded 5G or LTE modem means that connectivity is always available from day 1 without waiting for a wired connection.

Ideal for Wireless WAN

For organizations moving to a Wireless WAN, the E300 offers the ability to pair 5G or LTE with a wired link and use a cellular link as a failover connection, hybrid WAN or a primary connection. For an all-wireless WAN, the E300 offers 5G or LTE performance, which can support the throughput needs of a small- or medium-sized office with the ability to add a second cellular connection to increase available bandwidth and reliability.

5G, SD-WAN, and Security Integration

5G has emerged as an essential WAN infrastructure to offer agile and reliable connections.The E300 Enterprise Router with 5G cellular intelligence makes it easy to deploy 5G-enabled networks while optimizing both cellular and wired traffic to enhance application performance. Security postures can be reinforced, and attack surfaces minimized with zero trust privileged access, protected IP addresses, detailed security policies and consolidated authentication usage.

Additionally, the E300 router can serve as the user equipment router for private cellular networks that provide reliable local area network connectivity where wireless LAN fails to meet the network needs due to large areas or excessive congestion.

Product TypeWireless Router
Technical Information
Wi-Fi GenerationWi-Fi 6
Network BandDual Band
MU-MIMO TechnologyYes
Wireless Specifications
Broadband Transmission TechnologyEthernet
Wireless LAN StandardIEEE 802.11ax
ISM BandYes
UNII BandYes
ISM Maximum Frequency2.40 GHz
UNII Maximum Frequency5 GHz
Total Wireless Transmission Speed221.75 MB/s
Encryption Standard
  • WPA3-Personal
  • WPA3-ENT
  • WPA-PSK
  • WPA2-PSK
  • WPA2-ENT
Interfaces/Ports
Total Number of Network Ports5
Number of Network (RJ-45) Ports4
USBYes
Number of Broadband (RJ-45) Ports1
USB StandardUSB 2.0 Type A
I/O Expansions
Total Number of Expansion Slots2
Expansion Slot Type
  • SFP+
  • Expansion Slot
Network & Communication
Ethernet Technology10 Gigabit Ethernet
VPN SupportedYes
Physical Characteristics
Form Factor
  • Desktop
  • Wall Mountable
Height1.70" (43.18 mm)
Width10.60" (269.24 mm)
Depth5.30" (134.62 mm)
Weight (Approximate)860 g
Miscellaneous
Package Contents
  • E300 Wireless Router
  • Power Supply
  • Wall Mount Screw Pack
  • Rubber Feet for Desktop Mounting
Certifications & Standards
  • UL/cUL
  • CB Scheme
  • EN 60950-1
  • EN 62368-1
Environmental Compliance
  • Waste Electrical and Electronic Equipment Directive (WEEE)
  • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
  • Restriction of Hazardous Substances (RoHS)
ConditionNo
UPC0840292712218
Warranty
Limited WarrantyLifetime
antennas (1)
power adapters (1)

Part No. 170717-000

CradlePoint AC Adapter - 120 V AC, 230 V AC Input

W/IBR1700 IBR900/IBR950 IBR600C

power cords (1)
power supplies (1)

Part No. 170716-001

CradlePoint Power Supply - 12 V DC Output

W/IBR1700 IBR900 IBR600C/IBR650C

radio modems (1)

Part No. BF-MC400-1200M-B

CradlePoint MC400 Modular Modem

UP FOR E300/E3000 ENT BR ROUTERS

wireless routers (6)

Part No. BF-MC20-BT

BLUETOOTH LOWENERGY 5.1 MODULE FOR E300/E3000 BRANCH ROUTERS

FOR E300/E3000 BRANCH ROUTERS

Part No. 170900-007

5G OUTDOOR BRANCH CAPTIVE MODEM 5GB MODEM NA USED W/IBR1700 AER2200

W2005-5GB 4.1GBPS MODEM NORTH

Part No. 170900-005

LTE CAPTIVE MODEM 300MBPS MODEM W/ IBR1700 AER2200 E300 & E3000

INDOOR L950-C7A (300MBPS MODEM)

Part No. 170900-001

LTE CAPTIVE MODEM 150MBPS MODEM AMERICAS USED WITH E300 & E3000

CBA550-150M-D 150MBPS MODEM

Part No. 170900-011

5G HIGH-BAND OUTDOOR BRANCH CAPTIVE MODEM 5GB NA USED W/IBR1700

CRADLEPOINT 5G HIGHBD OUT BR CAP 5GB NORTH US IBR1700/AER2200/E300/E3000

Part No. BF-MC400-5GB

5G MODEM REQ 4FF SIM UPG FOR PERPE300/E3000 BRANCH ROUTERS

UPGRADE FOR E300/E3000 BR ROUTERS
