Atlona 4×2 Matrix Switcher with USB Hub and HDBaseT Input

Part No. AT-OME-MS42-HDBT

by Atlona Technologies

Atlona 4×2 Matrix Switcher with USB Hub and HDBaseT Input

4096 x 2160 - 4K UHD - Display, Notebook - 1 x HDMI Out

Part No. AT-OME-MS42-HDBT

by Atlona Technologies

$2059.99
General Information
ManufacturerAtlona Technologies
Manufacturer Part NumberAT-OME-MS42-HDBT
Brand NameAtlona
Product Name4×2 Matrix Switcher with USB Hub and HDBaseT Input
Marketing Information

Specifically designed for modern collaboration spaces


Ready for two displays.

The OME-MS42-HDBT is well-equipped for the requirements of the contemporary meeting room, which typically calls for two displays.

Remote AV input for presenter convenience.

The HDBaseT input on this switcher allows the OME-MS42-HDBT to be installed in a credenza, with a transmitter placed wherever convenient for a presenter to access.


Hands-free operation with a single-cable connection.

Connect and forget with a single USB-C cable connection to a laptop. The OME-MS42-HDBT takes care of the video, audio, USB interfacing, and delivers power to the laptop.

Additional Features

The Atlona AT-OME-MS42-HDBT is a versatile 4×2 matrix switcher withUSB-C, HDBaseT, and HDMI video inputs, and HDMI and HDBaseT outputs. It's perfect for video conferencing and collaboration applications with USB interfacing, and extension to a display and a remote AV input location.

HDBaseT input and output

The OME-MS42-HDBT extends AV, USB, control, and power up to 330 feet (100 meters) to a display and a location for AV input, such as a wall or meeting table.

USB host integration

Connect and switch between up to four USB host sources, including three connected to the switcher, and the fourth remotely over HDBaseT.

AV and USB host switching

AV inputs and USB hosts can be independently switched, or together for convenience. Automatic switching is available for AV and USB.

USB hub and extension

The OME-MS42 features an integrated USB 2.0 hub for peripherals, which can be expanded over HDBaseT to the transmitter and receiver.


Product TypeVideo Switchbox
Technical Information
Connectivity TechnologyCable
Device Supported
  • Display
  • Notebook
Video
Graphics Modes4K UHD
Maximum Video Resolution4096 x 2160
Interfaces/Ports
HDMI InYes
HDMI OutYes
USBYes
Connectivity (RJ-45)Yes
Number of Connectivity (RJ-45) Ports3
Number of USB Ports3
Number of HDMI Inputs2
Number of HDMI Outputs1
Media & Performance
Maximum Operating Distance330 ft (100584 mm)
Physical Characteristics
Form FactorWall Mountable
Height1.73" (43.94 mm)
Width8.64" (219.46 mm)
Depth10" (254 mm)
Weight (Approximate)1.57 kg
Miscellaneous
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
TAA CompliantYes
ConditionNo
Warranty
Limited Warranty3 Year
