Tripp Lite series 45U SmartRack Wide Premium Enclosure (Includes Doors and Side Panels)
On back-order, will ship once in-stock
- All Locations: (0+)
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SR45UBWD |
| Brand Name | Tripp Lite series |
| Product Line | SmartRack |
| Product Model | SR45UBWD |
| Product Name | 45U SmartRack Wide Premium Enclosure (Includes Doors and Side Panels) |
| Marketing Information | The SR45UBWD is a WIDE version of our standard 45U SmartRack. This enclosure is 750mm wide (29.5") compared to the standard 600mm wide (23.6"). This extra width allows for high density equipment installations. It allows cable management and PDU mounting off to the sides of the rack in order to keep these items out of the airflow for proper cooling. The SR45UBWD features a massive front-to rear-ventilation capacity that meets or exceeds server manufacturer requirements. Its integrated baying tabs make it easy to combine multiple enclosures in rows for data center applications. This enclosure is also compatible with hot-aisle/cold-aisle configurations. With its locking, reversible, removable front and rear doors, and locking, removable side panels, the SR45UBWD provides ultimate equipment safety. The side panels are half size for ease of removal and reinstallation. The split rear door design allows the enclosure to be placed closer to a wall. The SR45UBWD meets all requirements toward PCI DSS compliance. The top panel of the SR45UBWD is vented to help remove warm air from the enclosure and draw in cool air by convection. The top panel includes ports for cable routing, and can be quickly removed without tools. To facilitate cable access, the SR45UBWD is open-bottom. All components of the SR45UBWD are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection to the facility earth ground. The removable front and rear doors feature quick-release ground wires. It houses 3000 lb of standard 19-inch rack equipment in 45U. To simplify deployment, the SR45UBWD comes with preinstalled casters that enable it to be easily maneuvered into the desired location, where it can be secured by adjusting the preinstalled levelers. Note: the casters are intended for minor position adjustments and are not designed for moving the enclosure over long distances. The SR45UBWD comes with a 5-year product warranty. As part of the SmartRack family, the SR45UBWD is compatible with Tripp Lite's extensive range of rackmount accessories, enabling you to customize your solution to meet any requirement. |
| Product Type | Rack Cabinet |
| Color Family | Black |
| Product Color | Black |
| Units Per Pallet | 1 |
| Dynamic/Rolling Weight Capacity | 2250 lb (1020582.83 g) |
| Static/Stationary Weight Capacity | 3000 lb (1360777.11 g) |
| Height | 83.75" (2127.25 mm) |
| Width | 29.53" (750.06 mm) |
| Depth | 43" (1092.20 mm) |
| Weight (Approximate) | 339.51 lb (154000 g) |
| Rack Height | 45U |
| Rack Width | 19" (482.60 mm) |
| Package Contents |
|
| Additional Information |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Condition | No |
| UPC | 0037332175038 |
| Limited Warranty | 5 Year |
Part No. SRCOMBO
79774T Tripp Lite SmartRack SRCOMBO Combination Lock For Door - Combination - 2 PackLOCK FOR RACK ENCLOSURE CABINET
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRCABLERING2U
38473W Tripp Lite SRCABLERING2U - Cable Organizer - Black - 2U Rack Height x 19" Panel WidthFLEXIBLE RING TYPE
On back-order, will ship once in-stock
- All Locations: (0+)
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRCABLEDUCT1U
60588J Tripp Lite Horizontal Cable Manager - Cable Cover - Black - 1U Rack Height x 19" Panel WidthCABLE MANAGER FINGER
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRCABLEDUCT2UHD
98430Q Tripp Lite series SRCABLEDUCT2UHD Cable Pass-through - Cable Organizer - Black - 2U Rack Height x 19" Panel Width - SteelMANAGER STEEL WITH FINGER DUCT 2URM
In Stock Availability
- All Locations: (7+)
- Calgary, AB (1+)
- Mississauga, ON (6+)
Part No. SRCABLELADDER
38872W Tripp Lite SRCABLELADDER Route Cable Overhead - Cable Ladder2SECTIONS REQ SRCABLETRAY
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRCABLETRAYEXP
67480W Tripp Lite SRCABLETRAYEXP - Cable GuideEXPANSION REQUIRES SRCABLETRAY
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRCABLEVRT3
67482W Tripp Lite series SmartRack SRCABLEVRT3 Vertical Cable Manager - Cable Manager - Black - SteelCABL MNGR DOUBLE FINGER DUCT
In Stock Availability
- All Locations: (2+)
- Mississauga, ON (2+)
Part No. SRCABLEDUCT1UHD
98429Q Tripp Lite series SRCABLEDUCT1UHD Cable Pass-through - Cable Organizer - Black - 1U Rack Height x 19" Panel Width - SteelMANAGER STEEL WITH FINGER DUCT 1URM
In Stock Availability
- All Locations: (3+)
- Mississauga, ON (3+)
In Stock Availability
- All Locations: (4+)
- Mississauga, ON (4+)
Part No. SR1UBRUSH
67467W Tripp Lite series SR1UBRUSH Cable Pass-Through Panel with Brush Strip - Cable Pass-through - Black - 1U Rack HeightWITH BRUSH STRIP
In Stock Availability
- All Locations: (2+)
- Calgary, AB (2+)
Part No. SRCABLERING1U
60586J Tripp Lite SRCABLERING1U - Cable Panel - Black - 1U Rack Height x 19" Panel Width - SteelCABLE MANAGER RING
In Stock Availability
- All Locations: (8+)
- Calgary, AB (2+)
- Mississauga, ON (3+)
- Richmond, BC (3+)
- Toronto, ON (7+)
- Vancouver, BC (1+)
In Stock Availability
- All Locations: (6+)
- Mississauga, ON (6+)
Part No. SRXFAN3U
60581J Tripp Lite 3U rack mount fan panel - 230V - 3 Fan - 230 V AC - 3U - 1570.9 gal/min (5946537.79 mL/min) - BlackPANEL 230V
On back-order, will ship once in-stock
- All Locations: (0+)
On back-order, will ship once in-stock
- All Locations: (0+)
In Stock Availability
- All Locations: (8+)
- Calgary, AB (1+)
- Mississauga, ON (7+)
Part No. SRCAGENUTS1224
45203W Tripp Lite series Square Hole Hardware Kit (Includes 50 Pcs 12-24 Screws and Washers.) - Cage Nut, Rack Screw, Cup Washer - Pan - 50HARDWARE 12-24 SCREWS WASHERS
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRCAGENUT5MM
18201X Tripp Lite series Square Hole Hardware Kit (Includes 50 M5 screws and washers.) - Cage Nut, Pan Head Screw, Cup Washer - 50HARDWARE M5 SCREWS WASHERS
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRFILTER
62348S Tripp Lite series Filter Kit for SmartRack EnclosuresCABINET FILTER KIT 25U/42U/45U/48U
In Stock Availability
- All Locations: (9+)
- Mississauga, ON (9+)
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRVRTRAIL23
79795T Tripp Lite series SRVRTRAIL23 Mounting Rail Kit for Rack - Black - 4CABINET 23IN WIDE VERTICAL RAIL MNT
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRSTABILIZE
51565V Tripp Lite Anti-tip stabilizer plate for 25/42/47U cabinets - SteelPLATE KIT
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. UPSHDEARKIT
25890Y Tripp Lite UPSHDEARKIT Front Mount UPS Brackets - Steel - 29.48 kgEAR KIT
On back-order, will ship once in-stock
- All Locations: (0+)
In Stock Availability
- All Locations: (2+)
- Toronto, ON (12+)
In Stock Availability
- All Locations: (7+)
- Mississauga, ON (7+)
Part No. SRSWITCH
67489W Tripp Lite SRSWITCH Magnetic Door Switch Kit - DoorFRONTREAR DOORS REQ ENVIROSENSE
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRSHELF4PSL
60574J Tripp Lite SmartRack SRSHELF4PSL Rack Shelf - Black - Cold-rolled Steel (CRS) - 50 lb (22679.62 g) Maximum Weight CapacitySLIDING SHELF
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRSHELF4PKYBD
67487W Tripp Lite SRSHELF4PKYBD - Black - Cold-rolled Steel (CRS) - 25 lb (11339.81 g) Maximum Weight CapacityCAPACITY 16IN/406 MM DEPTH
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRSHELF4PSLHD
21864W Tripp Lite SRSHELF4PSLHD Rack Shelf - Black - Cold-rolled Steel (CRS) - 100 lb (45359.24 g) Maximum Weight Capacity91KG CAPACITY 26IN 660MM DEPTH
On back-order, will ship once in-stock
- All Locations: (0+)
Part No. SRSHELF2P1U
55946R Tripp Lite series SRSHELF2P1U Cantilever Fixed Rack Shelf - 1U Rack Height - Black - Cold-rolled Steel (CRS) - 40 lb (18143.69 g) Maximum Weight Capacity40LB CAPACITY F/ RACK ENCL CABINET
In Stock Availability
- All Locations: (166+)
- Calgary, AB (27+)
- Halifax, NS (6+)
- Mississauga, ON (123+)
- Toronto, ON (19+)
- Vancouver, BC (5+)
On back-order, will ship once in-stock
- All Locations: (0+)
In Stock Availability
- All Locations: (11+)
- Mississauga, ON (9+)
- Toronto, ON (2+)
In Stock Availability
- All Locations: (4+)
- Mississauga, ON (3+)
- Richmond, BC (1+)
- Toronto, ON (1+)
Part No. SRCASTERHDKIT
14153T Tripp Lite series Heavy-Duty Rolling Caster Kit (includes 4 Casters) - 750 lb (340194.28 g) Load CapacityDUTY MOBILE ROLLING CASTER KIT
On back-order, will ship once in-stock
- All Locations: (0+)
