Minuteman 1500 VA On-line Tower UPS with 6 0utlets

Tower - 5 Minute Stand-by - 120 V AC Input - 110 V AC, 120 V AC, 127 V AC Output - Serial Port - 6 x NEMA 5-15R Receptacle(s)

Part No. EC1500LCD

$1449.99

General Information

Manufacturer	Para Systems, Inc
Manufacturer Part Number	EC1500LCD
Brand Name	Minuteman
Product Line	Encompass
Product Model	EC1500LCD
Product Name	1500 VA On-line Tower UPS with 6 0utlets
Marketing Information	On-Line UPS, Comprehensive Protection Minuteman's Encompass Series delivers the comprehensive protection only offered by a true on-line UPS. By totally regenerating the incoming AC signal through double-conversion technology, an on-line UPS provides an impenetrable "electrical firewall," providing the most fail-safe power protection available. Designed to protect the most critical equipment used in data centers, voice and data communications, security systems, and light industrial applications. The Encompass Series is SNMP-capable (card optional) and allows full-device management using Minuteman's SentryHD™ power monitoring and control software. The Encompass product line is a value-priced on-line UPS solution that provides an outstanding set of features, true sinewave output, a three-year warranty (including batteries), and is designed to meet the reliability expectations of even the most demanding critical applications. Two form factors are available in the Encompass Series: a tower-only version (EC-LCD) and a rack/tower version (EC-RT).
Product Type	Double Conversion Online UPS

Technical Information

Plug/Connector Type	NEMA 5-15P
Receptacle Type	NEMA 5-15R
Receptacle Detail	6 x NEMA 5-15R
Dataline Protection	RJ-45 RJ-11
Transfer Time	0 ns
EMI/RFI Noise Filter	Yes
Application/Usage	Voice/Data Network Server Electronic Device Medical Healthcare Lab Equipment Security System Education Network

Power Description

Management

Network Management	SNMP Manageable

Controls/Indicators

Status Indicators	LCD Status Panel Alarm

Interfaces/Ports

Battery Information

Number of Batteries	1
Battery Characteristics	Sealed, Non-spillable, Maintenance-free
Battery Chemistry	Lead Acid
Backup/Run Time (Full Load)	5 Minute
Backup/Run Time (Half Load)	15 Minute
Hot Swappable	Yes
Replaceable Battery	Yes

Environmental Conditions

Maximum Operating Temperature	104°F (40°C)
Storage Temperature	14°F (-10°C) - 122°F (50°C)
Maximum Operating Elevation	10000 ft (3048000 mm)
Maximum Storage Elevation	50000 ft (15240000 mm)
Operating Humidity	10% - 90%
Storage Relative Humidity	10% - 90%
Sound Emission (A-Weighted)	55 dB(A)

Physical Characteristics

Miscellaneous

Package Contents	1500 VA On-line Tower UPS with 6 0utlets Batteries Disconnected Quick Installation Guide
Software Included	Minuteman SentryHD Power Monitoring and Control Software
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS) 2
Condition	No
UPC	784755155382
