TP-Link Omada 48-Port Gigabit Stackable Lite L3 Managed PoE++ Switch with 4× 10G Slots

Part No. SG5452XMPP

by TP-LINK Technologies Co., Ltd

$1473.99

On back-order, will ship once in-stock

  • All Locations: (0+)

TP-Link Omada 48-Port Gigabit Stackable Lite L3 Managed PoE++ Switch with 4× 10G Slots

48 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 10/100/1000Base-T, 10GBase-X - 3 Layer Supported - 942.70 W Power Consumption - 770 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Rack-mountable

Part No. SG5452XMPP

by TP-LINK Technologies Co., Ltd

$1473.99

On back-order, will ship once in-stock

  • All Locations: (0+)

General Information
ManufacturerTP-LINK Technologies Co., Ltd
Manufacturer Part NumberSG5452XMPP
Brand NameTP-Link
Product LineOmada
Product ModelSG5452XMPP
Product NameOmada 48-Port Gigabit Stackable Lite L3 Managed PoE++ Switch with 4× 10G Slots
Product TypeEthernet Switch
Technical Information
Features
  • DHCP Snooping
  • Zero-Touch Provisioning (ZTP)
  • Energy Efficient
Interfaces/Ports
Total Number of Network Ports48
Uplink PortYes
Stack PortYes
Port/Expansion Slot Details
  • 8 x Gigabit Ethernet PoE++
  • 40 x Gigabit Ethernet PoE+
  • 4 x 10 Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported
  • Twisted Pair
  • Optical Fiber
Ethernet Technology
  • Gigabit Ethernet
  • 10 Gigabit Ethernet
Network Technology
  • 10/100/1000Base-T
  • 10GBase-X
I/O Expansions
Total Number of Expansion Slots4
Expansion Slot TypeSFP+
Number of SFP+ Slots4
Network & Communication
Layer Supported3
Networking Standards
  • IEEE 802.1x
  • IEEE 802.3x
  • IEEE 802.3ad
  • IEEE 802.1Q
  • IEEE 802.1D
  • IEEE 802.1w
  • IEEE 802.1s
  • IEEE 802.1ab
  • IEEE 802.1p
  • IEEE 802.3az
  • IEEE 802.3af
  • IEEE 802.3at
Management & Protocols
ManageableYes
Power Description
PoE (RJ-45) PortYes
PoE Budget770 W
Input Voltage
  • 120 V AC
  • 230 V AC
Frequency
  • 50 Hz
  • 60 Hz
Power Source
  • Power Supply
  • AC
  • PoE++
  • PoE+
Power Consumption942.70 W
Physical Characteristics
Product MaterialMetal
Form FactorRack-mountable
Height1.70" (43.18 mm)
Width17.30" (439.42 mm)
Depth13" (330.20 mm)
Miscellaneous
Application/Usage
  • Network
  • Wireless Access Point
  • Business
  • Outdoor
  • Security
  • IP Phone
  • Camera
  • Surveillance
ConditionNo
UPC810142823241
