NEC Display MultiSync EX241UN-TMX4F 24" Class Full HD LCD Monitor - 16:9

24" Viewable - LED Backlight - 1920 x 1080 - 16.7 Million Colors - 250 cd/m² - 6 ms - Speakers - DVI - HDMI - VGA - DisplayPort

Part No. EX241UN-TMX4F

by Sharp

$3005.99

User Manual

Specifications
Options & Accessories (2)

General Information

Manufacturer	Sharp
Manufacturer Part Number	EX241UN-TMX4F
Brand Name	NEC Display
Product Line	MultiSync
Product Model	EX241UN-TMX4F
Product Name	MultiSync EX241UN 2x2 Video Matrix Bundle with Freestanding Desktop Stand
Marketing Information	A complete desktop video matrix solution in a box. The 24" NEC MultiSync EX241UN is a 4-sided ultra-narrow bezel IPS desktop monitor designed to put your image front and center. This slim, widescreen model features IPS panel technology with wide viewing angles (178° horizontal/vertical) and ergonomic adjustability and 0.8mm bezels around the entire display. Its settings are controlled by a 5-way control button on the back with on-screen display (OSD) indicators for easy adjustment of key settings and the included ControlSync™ technology allows users to control the settings for up to 25 EX241UN displays in a multi-monitor configuration. Upon establishing one unit as the master, users are able to control many performance attributes of the multi-monitor setup in unison through the single monitor. Its comprehensive input panel includes HDMI, DisplayPort, DVI-D, VGA and 3-port USB 3.0 hub for connecting to the latest display sources. This bundle includes 4 MultiSync EX241UN displays, a Chief K3G220B grommet-mounted desktop stand and an ISOBAR 6 port surge suppressor. LED backlight technology provides for industry-leading low power consumption and less hazardous materials Height-adjust, pivot, tilt and swivel capabilities add flexibility and comfort to your viewing preferences Full connectivity, including DisplayPort, HDMI, DVI-D and VGA inputs 5-way control button with on screen display makes display adjustments simple Optional human and ambient light sensors (KT-SS1) automatically detect your work conditions to determine the proper display brightness, conserving power ECO Mode™ allows you to manually adjust the display's brightness to your liking, saving power and reducing your energy costs Dual direction pivot and the image flip feature allow users to arrange the thinnest inactive areas together for nearly seemless images NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations Compatible with SpectraViewII calibration software and the SVII-EA-KIT calibration kit
Product Type	LCD Monitor

Technical Information

Number of Screens	4
Screen Size Class	24"
Viewable Screen Size	24"
Screen Mode	Full HD
Response Time	6 ms
Aspect Ratio	16:9
Backlight Technology	LED

Video

Maximum Resolution	1920 x 1080
Color Supported	16.7 Million Colors
Contrast Ratio	1,000:1
Brightness	250 cd/m²

Audio

Speakers	Yes

Interfaces/Ports

DVI	Yes
HDMI	Yes
USB	Yes
VGA	Yes
DisplayPort	Yes

Built-in Devices

Built-in Devices	USB Hub

Power Description

Operating Power Consumption	116 W

Physical Characteristics

VESA Mount Compatible	Yes
VESA Mount Standard	100 x 100
Height with Stand	25.40" (645.16 mm)
Width with Stand	43.40" (1102.36 mm)
Depth with Stand	5.18" (131.57 mm)

Miscellaneous

Package Contents	MultiSync EX241UN-H-BK Widecreen LCD Monitor 1 x Chief K3F220B desktop stand 1 x ISOBAR 6 surge suppressor
Country of Origin	China
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Condition	No

Warranty

Limited Warranty	3 Year
