Supermicro SuperServer 2029P-TXRT Server Barebone System - 2U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support
On back-order, will ship once in-stock
- All Locations: (0+)
Manufacturer | Supermicro Computer, Inc |
Manufacturer Part Number | SYS-2029P-TXRT |
Brand Name | Supermicro |
Product Line | SuperServer |
Product Model | 2029P-TXRT |
Product Name | SuperServer 2029P-TXRT (Black) |
Product Type | Server Barebone System |
Number of Processors Supported | 2 |
Processor Socket | Socket P LGA-3647 |
Processor Supported |
|
64-bit Processing | Yes |
Chipset Manufacturer | Intel |
Chipset Model | C621 |
Maximum Memory Supported | 2 TB |
Memory Technology | DDR4 SDRAM |
Memory Standard | DDR4-2666/PC4-21300 |
Total Number of Memory Slots | 16 |
Controller Type | Serial ATA/600 |
RAID Supported | Yes |
Graphics Controller Model | AST2500 |
Ethernet Technology | 10 Gigabit Ethernet |
Number of Total Expansion Bays | 17 |
Number of External 5.25" Bays | 1 |
Total Number of Expansion Slots | 9 |
Number of PCI Express x8 Slots | 5 |
Number of PCI Express x16 Slots | 4 |
Total Number of USB Ports | 4 |
Number of USB 3.0 Ports | 2 |
Number of SATA Interfaces | 10 |
Input Voltage |
|
Number of Power Supplies Installed | 2 |
Maximum Power Supply Wattage | 1 kW |
Color Family | Black |
Product Color | Black |
Form Factor | Rack-mountable |
Rack Height | 2U |
Height | 3.50" (88.90 mm) |
Width | 17.20" (436.88 mm) |
Depth | 25.60" (650.24 mm) |
Weight (Approximate) | 36 lb (16329.33 g) |
Package Contents |
|
Environmentally Friendly | Yes |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Condition | No |
Limited Warranty | 3 Year |
