Advantech IDS-3215 15" Class XGA LCD Monitor

Part No. IDS-3215G-40XGA1E

by Advantech Co., Ltd

$626.99

Advantech IDS-3215 15" Class XGA LCD Monitor

15" Viewable - LED Backlight - 1024 x 768 - 16.2 Million Colors - 500 cd/m² - 23 ms - DVI - VGA

Part No. IDS-3215G-40XGA1E

by Advantech Co., Ltd

$626.99

Specifications
Options & Accessories (2)

General Information

Manufacturer	Advantech Co., Ltd
Manufacturer Part Number	IDS-3215G-40XGA1E
Brand Name	Advantech
Product Model	IDS-3215
Product Name	15" XGA Industrial Panel Mount Monitor
Marketing Information	The Advantech IDS-3215 Embedded Industrial Panel Mount Monitor series offers flexible options for LCD, touchscreen, signal interface and chassis mounting. The series with standard integrated frame design, supports rear and VESA mounting which brings the benefits of easy installation and provides flexibility for different applications.
Product Type	LCD Monitor

Technical Information

Number of Screens	1
Screen Size Class	15"
Viewable Screen Size	15"
Screen Mode	XGA
Response Time	23 ms
Horizontal Viewing Angle	176°
Vertical Viewing Angle	176°
Mount Type	Panel-mountable Rear Mount
Backlight Technology	LED
Features	Anti-reflective On-screen Display (OSD) AutoTune Power Switch
Glass Hardness	3H

Video

Maximum Resolution	1024 x 768
Color Supported	16.2 Million Colors
Native Contrast Ratio	2,500:1
Brightness	500 cd/m²

Interfaces/Ports

DVI	Yes
USB	Yes
VGA	Yes
Number of USB Ports	1
Number of DVI Ports	1
Number of VGA Ports	1

Physical Characteristics

VESA Mount Compatible	Yes
VESA Mount Standard	100 x 100
Height	11.46" (291 mm)
Width	14.37" (365 mm)
Depth	1.50" (38 mm)
Weight (Approximate)	9.48 lb (4300 g)

Miscellaneous

Package Contents	15" XGA Industrial Panel Mount Monitor 1 x VGA cable 15P(M) (180 cm) 8 x clamper 8 x clamper screw M4_25L 1 x cable clamp 1 x cable clamp screw 1 x cable tie
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Condition	No

Warranty

Limited Warranty	2 Year
